Mastech MS2109A Clamp Meter Digital 600A AC with Test Leads MS2109A
Clamp Meters

Mastech MS2109A Clamp Meter Digital 600A AC with Test Leads MS2109A

Digital AC/DC clamp meter & non-contact voltage detector, with flashlight. Double insulation (protection class 600V CAT III and pollution degree 2).

Capability to measure AC & DC voltage, AC & DC...

Digital AC/DC clamp meter & non-contact voltage detector, with flashlight. Double insulation (protection class 600V CAT III and pollution degree 2).

Capability to measure AC & DC voltage, AC & DC current, resistance, diodes, frequency, continuity check, temperature.

Data hold function.

Back light illumination.

Low battery indication and automatic shutdown...

See full description See full description
Product report

Description

Description

Digital AC/DC clamp meter & non-contact voltage detector, with flashlight. Double insulation (protection class 600V CAT III and pollution degree 2).

Capability to measure AC & DC voltage, AC & DC current, resistance, diodes, frequency, continuity check, temperature.

Data hold function.

Back light illumination.

Low battery indication and automatic shutdown after a certain period of inactivity.

Includes terminals, batteries, manual, and carrying case.

Technical Specifications:

  • Auto-ranging
  • Auto power off
  • REL Measurement
  • Diode measurement
  • Resistance continuity measurement
  • Maximum & minimum value measurement
  • Data Hold
  • Backlight
  • Low battery indicator
  • Jaw opening: Ф26mm/1.0"
  • DC Voltage: 600mV/6V/60V/600V ± (0.7%+2)
  • DC Current: 60A/ 600A ± (3.0%+6)
  • AC Voltage: 6V/ 60V ± (0.8%+3), 600V ± (1.0%+4)
  • AC Current: 60A/ 600A ± (2.5%+6)
  • Resistance: 600Ω/ 6KΩ/ 60KΩ/ 600KΩ ± (0.8%+3) :6MΩ/60MΩ ± (1.2%+3)
  • Frequency: A 99.99Hz/999.9Hz ±(1.5%+5) : V 99.99Hz/999.9Hz/9.999kHz ±(1.5%+5) : HZ/DUTY 9.999Hz/99.99Hz/999.9Hz/9.999kHz/ 99.99KHZ/999.9KHZ/9.999MHZ±(0.5%+3)
  • Capacitance: 40nF/ 400nF/ 4/40/400//4000μF± (4.0% +5)
  • Duty Cycle: 0.1%-99.9% ± (3.0% +5)
  • Temperature: -20°C ~ 1000°C ± (3.0% +4) -4°F~1832°F ± (1.0%+3)
  • Dimensions: 218mm×78mm×35mm
  • Weight: 239g
  • Safety Rating: CAT III 600V
  • Power Supply:
  • 3x AAA batteries (included)
  • Certificates: IOS 9001

Package includes:

  • Clamp meter
  • 1x pair of test leads
  • 1x K-type thermocouple
  • 3x AAA batteries
  • Carrying case
  • Manual

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

True RMS
No
with Test Leads
Yes

with Test Leads


It has measurement terminals that have a red wire for positive and a black wire for negative.
AC Current
600 A
Indication
Digital
Bluetooth
No
Safety Category
CAT III

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications

Reviews (2)

Reviews

5.0
2
5.0
Review this product
  1. 2
  2. 4 stars
    0
  3. 3 stars
    0
  4. 2 stars
    0
  5. 1 star
    0
Review this product

Description & Specifications

Digital AC/DC clamp meter & non-contact voltage detector, with flashlight. Double insulation (protection class 600V CAT III and pollution degree 2).

Capability to measure AC & DC voltage, AC & DC current, resistance, diodes, frequency, continuity check, temperature.

Data hold function.

Back light illumination.

Low battery indication and automatic shutdown after a certain period of inactivity.

Includes terminals, batteries, manual, and carrying case.

Technical Specifications:

  • Auto-ranging
  • Auto power off
  • REL Measurement
  • Diode measurement
  • Resistance continuity measurement
  • Maximum & minimum value measurement
  • Data Hold
  • Backlight
  • Low battery indicator
  • Jaw opening: Ф26mm/1.0"
  • DC Voltage: 600mV/6V/60V/600V ± (0.7%+2)
  • DC Current: 60A/ 600A ± (3.0%+6)
  • AC Voltage: 6V/ 60V ± (0.8%+3), 600V ± (1.0%+4)
  • AC Current: 60A/ 600A ± (2.5%+6)
  • Resistance: 600Ω/ 6KΩ/ 60KΩ/ 600KΩ ± (0.8%+3) :6MΩ/60MΩ ± (1.2%+3)
  • Frequency: A 99.99Hz/999.9Hz ±(1.5%+5) : V 99.99Hz/999.9Hz/9.999kHz ±(1.5%+5) : HZ/DUTY 9.999Hz/99.99Hz/999.9Hz/9.999kHz/ 99.99KHZ/999.9KHZ/9.999MHZ±(0.5%+3)
  • Capacitance: 40nF/ 400nF/ 4/40/400//4000μF± (4.0% +5)
  • Duty Cycle: 0.1%-99.9% ± (3.0% +5)
  • Temperature: -20°C ~ 1000°C ± (3.0% +4) -4°F~1832°F ± (1.0%+3)
  • Dimensions: 218mm×78mm×35mm
  • Weight: 239g
  • Safety Rating: CAT III 600V
  • Power Supply:
  • 3x AAA batteries (included)
  • Certificates: IOS 9001

Package includes:

  • Clamp meter
  • 1x pair of test leads
  • 1x K-type thermocouple
  • 3x AAA batteries
  • Carrying case
  • Manual

Manufacturer

Manufacturer Details

Warnings & Safety Information
True RMS
No
with Test Leads
Yes

with Test Leads


It has measurement terminals that have a red wire for positive and a black wire for negative.
AC Current
600 A
Indication
Digital
Bluetooth
No
Safety Category
CAT III

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
