- DC Current: 60 A / 600 A ± (2.5% + 5)
- AC Current: 60 A / 600 A ± (2.5% + 5)
- DC Voltage: 600 mV / 6 V / 60 V / 600 V / 1000 V ± (0.8% + 1)
- AC Voltage: 6 V / 60 V / 600 V / 750 V ± (1.2% + 5)
- Resistance: 600 ohms / 6 ohm / 60 ohm / 600 ohm / 6 MOhm / 60 Mohm ± (1% + 2)
- Capacitance: 60 nF / 600 nF / 6 uF / 60 uF / 600 uF / 6 mF / 60 mF ± (4% + 5)
- Frequency: 10 Hz-1 MHz ± (0.1% + 4)
- Temperature: -40 °C-1000 °C ± (2.5% + 3) -40 °F-1832 °F ± (2.5% + 4)
- Maximum Reading: 6000
- Automatic Test Range Switching
- Jaw Opening: 30 mm
- True RMS
- Diode: approx. 3 volts
- VFC - AC Measurement for Frequency Change
- NCV - Electric Field Detection
- Last Screen Freeze
- Device Zeroing Function
- Relative Function
- Maximum / Minimum
- Surge Current
- Illuminated LCD
- Analog Bar Graph: 61 segments
- Measurement Point Lighting
- Automatic Shut-off: after approximately 15 minutes
- Circuit Continuity
- Low Battery Indicator: = <3.6 V
- Circuit Input Protection
- Input Voltage Resistance: >= 10 MOhm
- Power Supply: 1.5 V 3x AAA
- Screen Size: 38 x 24 mm
- Product Dimensions: 220 × 75 x 40 mm
- Product Weight: 231.7 g
- True RMS
- Yes
- with Test Leads
- No
- AC Current
- 600 A
- Indication
- Digital
- Bluetooth
- No
- Safety Category
- CAT II
