The Mackie MX3500 PA power amplifier delivers 1000 W per channel at 8 Ω and 1350 W per channel at 4 Ω. It supports parallel, stereo, or bridged operation, with a bridged output of 2700 W at 8 Ω, and features selectable input sensitivity.
Each channel has independent level controls and Signal, Clip, and Fault indicators. The rugged 2U steel chassis is impact-resistant, while the cooling system is complemented by protection against short circuits, low impedance, overcurrent, and overheating.
- Type: PA power amplifier
- Channels: 2
- Power per channel at 8 Ω: 1000 W
- Power per channel at 4 Ω: 1350 W
- Bridged power at 8 Ω: 2700 W
- Modes: Parallel, stereo, and bridged
- Input sensitivity: Selectable
- Level control: Independent per channel
- Indicators: Signal, Clip, and Fault per channel
- Inputs: XLR
- Outputs: NL4
- Cooling system: Included
- Protection: Short-circuit, low-impedance, overcurrent, and overheating protection
- Chassis: Impact-resistant 2U steel
- Width: 483 mm
- Height: 88 mm
- Depth: 370 mm
- Weight: 18.3 kg
Technical Specifications
- Amplifier Type
- PA Amplifier
- Type
- Power Amplifier
- Channels
- 2
- Power (8Ω)
- 1000 watt / channel
- Power (4Ω)
- 1350 watt / channel
- Weight
- 18.3 kg
Additional Specifications
- Radio
- No
- Cooling system
- Yes
Connectivity
- RCA
- No
- XLR
- Yes
- Mini Jack (3.5mm)
- No
- Jack (6.3mm)
- No
- USB
- No
- Ethernet
- No
- Bluetooth
- No
- Mic In
- No
Dimensions
- Width
- 483 mm
- Height
- 88 mm
- Length
- 370 mm
