- 18x20 USB2.0 audio/MIDI interface with ADAT I/O for recording microphones and instruments
- Audiophile 24-Bit/96 kHz resolution for professional audio quality
- Compatible with popular recording software, including Avid Pro Tools, Ableton Live, Steinberg Cubase, etc.
- Streams 18 inputs and 20 outputs with ultra-low latency to your computer, supporting Mac OS X and Windows XP or later
- 8 state-of-the-art Midas-designed microphone preamps with +48 V phantom power
- Optical I/O supporting S/PDIF, ADAT, and S/MUX formats up to 96 kHz
- Simultaneous use of all analog, coaxial S/PDIF, optical ADAT, and MIDI signals
- Direct zero-latency monitoring of all analog inputs during recording
- ADAT input allows combination with Behringer ADA8200 (not included) for expansion to a total of 16 Midas-designed microphone preamps
- Input/Playback Mix control and Stereo/Mono switch for direct monitoring
- Powerful dual headphone outputs with individual level controls and A/B monitor source selection for DJ-style cueing
- Main outputs with Dim, Mute, and dedicated main level control
- 19", 1U rackmount chassis with detachable rack ears
- Metal chassis "Built like a tank".
Description
Specifications
- USB 2.0 audio interface, 18 x 20
- Up to 24-bit / 96 kHz
- 18 Inputs and 20 Outputs: 8x XLR / 6.3 mm combo microphone / instrument / line input, switchable
- MIDAS preamplifier
- 2 optical ADAT / SPDIF inputs and outputs (S/MUX capable)
- 2 coaxial SPDIF inputs and outputs
- 10 x 6.3 mm jack line outputs (1 + 2 monitor output L/R)
- Phantom power +48 V can be enabled
- Pad switch for each input
- Main output control with mute and DIM switch
- Monitoring control with stereo / mono switch
- 2 separate headphone outputs with control
- MIDI input and output
- External power supply
- Compatible with Windows XP / Vista / 7 / 8 / 10 and Mac OSX
Features
- 18x20 USB2.0 audio/MIDI interface with ADAT I/O for recording microphones and instruments
- Audiophile 24-Bit/96 kHz resolution for professional audio quality
- Compatible with popular recording software, including Avid Pro Tools, Ableton Live, Steinberg Cubase, etc.
- Streams 18 inputs and 20 outputs with ultra-low latency to your computer, supporting Mac OS X and Windows XP or later
- 8 state-of-the-art Midas-designed microphone preamps with +48 V phantom power
- Optical I/O supporting S/PDIF, ADAT, and S/MUX formats up to 96 kHz
- Simultaneous use of all analog, coaxial S/PDIF, optical ADAT, and MIDI signals
- Direct zero-latency monitoring of all analog inputs during recording
- ADAT input allows combination with Behringer ADA8200 (not included) for expansion to a total of 16 Midas-designed microphone preamps
- Input/Playback Mix control and Stereo/Mono switch for direct monitoring
- Powerful dual headphone outputs with individual level controls and A/B monitor source selection for DJ-style cueing
- Main outputs with Dim, Mute, and dedicated main level control
- 19", 1U rackmount chassis with detachable rack ears
- Metal chassis "Built like a tank".
Connectivity
- PC Connectivity
- USB
Dimensions
- Card Type
- Rack
- Audio Resolution
- 24-bit / 96kHz
- Phantom Power
- Yes
- MIDI
- Yes
- Loopback
- -
- Auto Gain
- -
- Clip Safe
- -
- DSP
- -
- Word Clock
- -
- Colour
- Black
Audio Ports
- XLR Input
- 8
- Headphones
- Yes
- 6.3mm Input
- 8
- 6.3mm Output
- 6
- 3.5mm
- No
- RCA
- No
Compatibility
- Compatible Software
- Windows
Bundle Contents
- Contents
- Headphones, Microphone
Important information
Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
