The Vogel & Noot Vienna Line panel radiator features a three-column Type 33 construction and a side connection. It is made of 1.25 mm cold-rolled steel sheet and painted in accordance with DIN 55900 specifications. Its heat output is certified to DIN 4704 and BS EN 442.
The radiator is pressure-tested at 10 bar and operates at a maximum allowable pressure of 7.7 bar and a temperature of 120°C. The package includes brackets and mounting hardware.
- Type: Panel
- Column type: 33
- Installation type: Side connection
- Heat output: 1369 kcal/h
- Height: 300 mm
- Length: 800 mm
- Color: White
- Material: Cold-rolled steel sheet
- Sheet thickness: 1.25 mm
- Test pressure: 10 bar
- Maximum operating pressure: 7.7 bar
- Maximum operating temperature: 120°C
- Painting standards: DIN 55900
- Performance standards: DIN 4704, BS EN 442
- Package contents: Brackets and mounting hardware
- Type
- Panel
- Heating Efficiency (kcal/h)
- 1369 kcal/h
- Installation Type
- External Loop
- Type of Columns
- 33
- Colour
- White
- Height
- 300 mm
- Length
- 800 mm
