Autotech IQ1000 Garage Door Control Panel Single-Phase (220V) 500W 230 VAC
Garage Door Control Panels

Autotech IQ1000 Garage Door Control Panel Single-Phase (220V) 500W 230 VAC

The Autotech iQ-1000 control unit operates roller shutters powered by a single-phase 230 VAC supply and equipped with their own limit switches. The built-in remote control receiver operates at 433.92...

The Autotech iQ-1000 control unit operates roller shutters powered by a single-phase 230 VAC supply and equipped with their own limit switches. The built-in remote control receiver operates at 433.92 MHz with rolling-code technology and is compatible only with Autotech RCX remotes. It has an input for a push button operating at 230 VAC.

For safety, the...

See full description See full description

Learn more about invoicing
Product report

Description

Description

The Autotech iQ-1000 control unit operates roller shutters powered by a single-phase 230 VAC supply and equipped with their own limit switches. The built-in remote control receiver operates at 433.92 MHz with rolling-code technology and is compatible only with Autotech RCX remotes. It has an input for a push button operating at 230 VAC.

For safety, the control unit automatically cuts off the power after up to 2 minutes in the event of a limit switch failure. It does not support safety photocells or detect power interruption by the motor’s limit switches. Remote controls are programmed using the Auto Learn button.

  • Power supply: Single-phase, 230 VAC
  • Power: 500 W
  • Maximum motor current: 5 A/250 VAC
  • Receiver frequency: 433.92 MHz
  • Coding: Rolling code
  • Compatible remotes: Autotech RCX
  • Control input: For a 230 VAC push button
  • Maximum operating time: 2 min
  • Safety photocells: Not supported
  • Dimensions: 44 × 44 × 25 mm

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Power
500 W
Power Source
Single-Phase (220V)
Frequency
433.92 MHz
Wi-Fi
No

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications
