LED Panels

Eurolamp Round Recessed LED Panel 20W with Cool White Light 6500K 22.5cm

Key features:

  • Cool White Light
  • Brightness: 1800 lumens
See full description

Description

Description

Nominal Power: 20W

Input Voltage: 85-265V

Output Voltage: 55-65V DC

Operating Frequency: 50/60Hz

Color Temperature: 6500K

Luminous Flux: 1800lm

Lumen/ Watt: 90lm/Watt

Flicker-free: Yes

Lumen/ Chip: 28lm/Chip

Total Chips: 90pcs

Watt/ Chip: 0.2W/Chip

Chip Size: 1028

Chip Brand: Sanan

Driver Brand: VTP

Driver Included: Yes

LED Type: SMD2835

Power Factor: >0.50

Color Rendering Index (CRI): >80

Dimmable: No

Lifetime: 30000h

Ingress Protection: IP20

Beam Angle: 120°

Start-up Time: 0.5 sec

Energy Class: F

Switching Cycles (ON/OFF): 15000

Operating Temperature: -10°C - +60°C

Installation Height: 2 - 3mtr

Product Material: Aluminum & Plastic

Product Color: White

Dimensions:

  • Length: 225mm
  • Width: 225mm
  • Height: 10.5mm
  • Diameter: Φ225mm
  • Cut-out Size: Φ210mm

Gross Product Weight: 0.335Kg

Packaging: Color Box

Certificates: Yes

CE Mark: Yes

Class: Class II

Connection Type: Cable

Object Grounding: No

Manufacturer

See full description

Specifications

Specifications

Specifications

Placement
Recessed
Shape
Round
Power
20 W
Color Temperature
6500 K
Light Colour
Cool White
Lumen
1800 lm

Dimensions

Length
22.5 cm
Length
22.5 cm
Height
1.05 cm

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
