Description
Specifications
Ideal for high-resolution transmissions (HDTV, Full HD, Ultra HD (UHD/4K and above)) for digital signals such as DVB-T and DVB-T2, radio (UKW/DAB/DAB+), and cable TV, DVB-C and DVB-C2 (analog/digital SD/digital HD).
Reliable connection between the wall socket and the receiving device, such as TV/receiver (Sky receiver) and radio.
- Cable sheath diameter (approx.): 8 mm
- Inner conductor diameter: 1.02 mm
- Dielectric diameter: 5
- Number of shields: 4 x
- Significance: WEEE, CE
- Resistance: 75 Ω
- Shielding effectiveness: 135 dB
- Lock protection: both sides
- Cable type: coaxial cable
- Inner conductor material: CU (copper)
- Shielding types:
- Type 1: foil (aluminum)
- Type 2: braid (aluminum) 128x
- Type 3: foil (aluminum)
- Type 4: braid (aluminum) 128x
- Connection frame material: aluminum
- Contact connection material: gold-plated
- Connection shielding: yes
- Connection type: Coaxial female (socket)
- Connection type 2: Coaxial male (plug)
- Color: white
- Consumption unit: 1 piece in polybag
- Cable length: 5 m
- Cable sheath material: PVC
- Color variation: white
- Terminal A
- Coax male
- Terminal B
- Coax female
- Length
- 5 m
- Gold Plated Terminal
- Yes
- Colour
- White
