Abb Automatic Circuit Breaker 25A Four-pole AC 70375
Automatic Circuit Breaker

Abb Automatic Circuit Breaker 25A Four-pole AC 70375

ABB Automatic Circuit Breaker 3.0kA C 4P 25A S204T-C25.

Advantages:

  • Two different triggering mechanisms: delayed thermal triggering mechanism for overload protection and electromechanical triggering...

ABB Automatic Circuit Breaker 3.0kA C 4P 25A S204T-C25.

Advantages:

  • Two different triggering mechanisms: delayed thermal triggering mechanism for overload protection and electromechanical triggering mechanism for short circuit protection.
  • Complies with IEC/EN 60898-1 standards, suitable for residential applications.
  • Auxiliary contact at the bottom for a 50%...
See full description See full description
Review the product
Product report

Description

Description

ABB Automatic Circuit Breaker 3.0kA C 4P 25A S204T-C25.

Advantages:

  • Two different triggering mechanisms: delayed thermal triggering mechanism for overload protection and electromechanical triggering mechanism for short circuit protection.
  • Complies with IEC/EN 60898-1 standards, suitable for residential applications.
  • Auxiliary contact at the bottom for a 50% space saving on S200.

Features:

  • Curve: C
  • Nominal Current: 25A
  • Frequency: 50/60Hz
  • Number of Elements-Poles: 4
  • Nominal breaking capacity: 3kA
  • Overvoltage category: III
  • Rigid cable cross-section: 0.75 ... 25 mm²
  • Flexible cable cross-section: 0.75 ... 16 mm²
  • Operating temperature: -25 ... +55 °C
  • Protection degree: IP20
  • Dimensions: Width: 70mm, Height: 88mm, Depth: 69mm

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Specifications

Number of Poles
4
Rated Current
25 A
Operating Curve
Curve C

Operating Curve

The tripping curve shows the time required for the circuit breaker to switch off in relation to the current passing through it. For small overcurrents, the tripping is delayed to avoid unnecessary interruptions, while for very high values, such as in the case of a short circuit, the breaker operates immediately to protect the circuit. Different types of curves are used depending on the needs of each installation and the type of loads.

Curve C

The most common in general installations, ideal for circuits with motors or electronic devices.

Power Supply

AC
Yes
DC
No

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications

Description & Specifications

ABB Automatic Circuit Breaker 3.0kA C 4P 25A S204T-C25.

Advantages:

  • Two different triggering mechanisms: delayed thermal triggering mechanism for overload protection and electromechanical triggering mechanism for short circuit protection.
  • Complies with IEC/EN 60898-1 standards, suitable for residential applications.
  • Auxiliary contact at the bottom for a 50% space saving on S200.

Features:

  • Curve: C
  • Nominal Current: 25A
  • Frequency: 50/60Hz
  • Number of Elements-Poles: 4
  • Nominal breaking capacity: 3kA
  • Overvoltage category: III
  • Rigid cable cross-section: 0.75 ... 25 mm²
  • Flexible cable cross-section: 0.75 ... 16 mm²
  • Operating temperature: -25 ... +55 °C
  • Protection degree: IP20
  • Dimensions: Width: 70mm, Height: 88mm, Depth: 69mm

Manufacturer

Manufacturer Details

Warnings & Safety Information

Specifications

Number of Poles
4
Rated Current
25 A
Operating Curve
Curve C

Operating Curve

The tripping curve shows the time required for the circuit breaker to switch off in relation to the current passing through it. For small overcurrents, the tripping is delayed to avoid unnecessary interruptions, while for very high values, such as in the case of a short circuit, the breaker operates immediately to protect the circuit. Different types of curves are used depending on the needs of each installation and the type of loads.

Curve C

The most common in general installations, ideal for circuits with motors or electronic devices.

Power Supply

AC
Yes
DC
No

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
