The Hager SVN125 single panel indicator light uses an LED light source and is white. It is designed for installation in electrical distribution boards and control panels, where it occupies 1 module.
- Light source: LED
- Colour: White
- Cover: Transparent
- Operating voltage: 230 V
- Voltage type: AC
- Rated insulation voltage: 250 V
- Impulse withstand voltage: 2000 V
- Total power loss at rated current In: 0.33 W
- Maximum light source power: 0.8 W
- Width in modules: 1
- Degree of protection: IP20
- Installed product height: 83 mm
- Installed product width: 17.5 mm
- Installed product depth: 62 mm
- Compliance certificates: CE, WEEE
- Quantity per package: 1
- Product Number
- SVN125
- Colour
- White
- Number of Indicator Lights
- Single
