The Mean Well SD-25B-5 LED power supply delivers 25 W of power and a 5 V output. The output voltage is adjustable via a trimmer, and the input-to-output galvanic isolation is 1500 VDC.
The built-in EMI filter helps reduce ripple noise. It includes short-circuit, overload, and overvoltage protection.
- Power: 25 W
- Output voltage: 5 V
- Output voltage adjustment: Via trimmer
- Input-to-output galvanic isolation: 1500 VDC
- EMI filter: Built-in
- Protections: Short-circuit, overload, and overvoltage
- Operating temperature: -10 to +60 °C
- Operating frequency: 83 kHz
- Dimensions: 99 × 97 × 36 mm
- Weight: 0.38 kg
- Output (DC)
- 5 V
- Power
- 25 W
Important information
Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
