Gacia Phase 4-Pole Earth Leakage Relay 25A 400V 4Χ25Α 6KA 300mA Type A
Phase Relays

Gacia Phase 4-Pole Earth Leakage Relay 25A 400V 4Χ25Α 6KA 300mA Type A

Key features:

  • Number of Poles: 4
  • Short Circuit Rating: 6kA
  • Nominal Voltage: 400V
  • Nominal Current: 25A
  • Leakage Current: 300mA
See Description & Specifications

Αριθμός πόλων / ένταση

  1. 4x100A

    from 25,24 €

  2. 4x25A

    from 24,13 €

  3. 4x32A

    from 24,13 €

  4. 4x40A

    from 24,13 €

  5. 4x63A

    from 28,95 €

  6. 4x80A

    from 25,24 €

24 13 €
Delivery by Thu, 19 Nov
14,00 €   shipping cost
Sent from Greece
From Lampa-shop 4.8 (27)
4.8 (27 reviews)
Greece
20+ pieces
See Electrical Panel Supplies on the page of Lampa-shop

Shop selection criteria

Why do we recommend buying from this shop?

We don’t only look at the price. We weigh different factors to find an offer that combines a good price, fast delivery and a reliable purchase.

  • Product price

    We calculate the total price you will pay and any discounts available from the shop.

  • Shipping & delivery time

    We check how quickly the product can be shipped and when you will receive it, based on your address.

  • Shop reliability

    We look at how often shops complete their orders successfully and how consistently they serve their customers.

  • Official reseller

    Where available, we take into account whether the shop is an official reseller of the brand.

Learn more about invoicing
Review the product
Product report

Description & Specifications

The Gacia 4-pole 25 A DIN-rail residual current circuit breaker interrupts the circuit in the event of a current leakage. It operates at 400 V and has a rated current of 25 A, a breaking capacity of 6 kA and a Type A characteristic.

  • Type: Residual current
  • Supply voltage: 400 V
  • Rated current: 25 A
  • Number of poles: 4
  • Residual current: 300 mA
  • Residual current device type: A
  • Breaking capacity: 6 kA
  • Operating frequency: 50/60 Hz
  • Ingress protection rating: IP20
  • Operating temperature: -25 °C to +50 °C
  • Colour: White
  • Material: Polyamide
  • Weight: 0.340 kg
  • Height: 81 mm
  • Width: 72 mm
  • Length: 74 mm
  • Cable cross-section: 4 mm
  • Copper busbar: 16 mm
  • Terminal connection type: Cable and L- and U-type copper busbar
  • Residual current protection type: Electronic
  • Fault indicator: Yes
  • Certification: IEC61008-1
  • Mechanical operations: 4000
  • Electrical operations: 2000

Manufacturer

Manufacturer Details

Warnings & Safety Information
Type
Earth Leakage
Number of Poles
4
Voltage
400 V
Nominal Voltage
25 A
Leakage Current
300 mA
with Energy Consumption Meter
No
with Timer
No
Type of Residual Current Relay
Type A

Important information
