Efficiency has always been one of the most important factors for users when choosing their power supply. While there are a range of performance options, 80 PLUS Gold has been the ideal choice in recent years and continues to be considered the standard for much of the world. The MWE Gold - V2 provides 80 PLUS Gold certification, ensuring a typical minimum efficiency of 90%.
Description
Specifications
The Silencio fan and exclusive LDB bearing provide nearly silent cooling without loss of system performance and longevity.
80 Plus Gold Certification
Efficiency has always been one of the most important factors for users when choosing their power supply. While there are a range of performance options, 80 PLUS Gold has been the ideal choice in recent years and continues to be considered the standard for much of the world. The MWE Gold - V2 provides 80 PLUS Gold certification, ensuring a typical minimum efficiency of 90%.
2 EPS Plugs
All MWE Gold - V2 models come standard with 2 EPS connectors to ensure universal compatibility with all current generation motherboards. Whether you are getting the minimum power level at 550W or the maximum at 850W, you never need to worry about having enough connectors to use the ideal components.
Silent Operation
The MWE Gold - V2 has been upgraded with an HDB fan. This fan bearing provides silent and efficient cooling with a long lifespan, allowing users to get the most out of their power supply for years to come. Some additional measures have been applied to the original MWE Gold to reduce sound production and ripple noise for a proven quieter user experience.
High Thermal Resistance
While the original MWE Gold had a maximum operating temperature of only 45 degrees Celsius, the MWE Gold - V2 has improved on this limit by providing an additional 5 degrees. With this model, users will be able to push their power supply to 50 degrees Celsius safely. Such a high limit significantly enhances what you can achieve with your power supply and your system in general. Overclocking and other high-intensity applications become much more feasible when the system's power supply can withstand the heat.
Flat Black Cables
The MWE Gold - V2 comes with black cables. These cables are easy to handle, fold, and maneuver for the most efficient use of space, thereby reducing clutter. This more efficient use of space within the case allows for reduced clutter and better airflow, thus improving the overall cooling of your system and lowering temperatures. The flat black cables also have the aesthetic advantage of being less noticeable and taking up less space when your components are displayed in a case with a transparent window.
Protection Technologies
The MWE provides full standard protection (OCP/OVP/UVP/SCP/OPP) as well as built-in overheating protection (OTP). These additional safety measures minimize the risk of damage to your system from power interruptions.
Connections
- 1x ATX 20 + 4-pin motherboard power connector.
- 1x EPS/ATX12V 8 Pin (4+4) CPU power connector
- 4x PCIe 6+2 graphics card power connectors, to take advantage of modern GPUs in combination with your PC's capabilities
- 8x SATA power connectors for SSD or HDD hard drives
- 4x Molex 4-pin connectors for additional peripherals
Compatibility with Graphics Cards & Processors
Nvidia
AMD
Dimensions
- Power
- 650 W
- Size
- ATX
- Modularity
- Full Modular
- Certification
- 80 Plus Gold
- Fan Dimension
- 120 mm
- Power Protection
- Over Power Protection (OPP), Over Temperature Protection (OTP), Over Voltage Protection (OVP), Short Circuit Protection (SCP), Under Voltage Protection (UVP)
- Color
- Black
ATX Version
- ATX 3.1
- -
Important information
Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
