Gacia Phase 4-Pole Earth Leakage Relay 25A 400V 4Χ25Α 6KA 30mA Type A

LEAKAGE RELAY 4X25A 6KA 30mA GACIA TYPE A

  • Color: White
  • Poles: 4P
  • Supply Voltage: 400V
  • Operating Frequency: 50/60Hz
  • Current Rating: 25A
  • Short-Circuit Breaking Capacity: 6kA
  • mA: 30mA
  • Ingress Protection...

LEAKAGE RELAY 4X25A 6KA 30mA GACIA TYPE A

  • Color: White
  • Poles: 4P
  • Supply Voltage: 400V
  • Operating Frequency: 50/60Hz
  • Current Rating: 25A
  • Short-Circuit Breaking Capacity: 6kA
  • mA: 30mA
  • Ingress Protection Rating: IP20
  • Length: 74mm
  • Width: 72mm
  • Height: 81mm
  • Gross Weight: 0.340kg
  • Packaging: 3\30
  • Certifications: Yes
  • Product Certification: IEC61008-1
  • CE Marking: Yes
  • ...
See full description See full description

Description

Description

LEAKAGE RELAY 4X25A 6KA 30mA GACIA TYPE A

  • Color: White
  • Poles: 4P
  • Supply Voltage: 400V
  • Operating Frequency: 50/60Hz
  • Current Rating: 25A
  • Short-Circuit Breaking Capacity: 6kA
  • mA: 30mA
  • Ingress Protection Rating: IP20
  • Length: 74mm
  • Width: 72mm
  • Height: 81mm
  • Gross Weight: 0.340kg
  • Packaging: 3\30
  • Certifications: Yes
  • Product Certification: IEC61008-1
  • CE Marking: Yes
  • Operating Temperature: -25°C - +50°C
  • Material: Polyamide
  • Operating Cycles: Mechanical: 4000, Electrical: 2000
  • Terminal Connection Type: Cable, Copper Bridge Type L & U
  • Residual Current Protection Type: Electronic
  • Residual Current Working Type: A
  • Error Indication: Yes

Manufacturer

See full description

Specifications

Specifications

Type
Earth Leakage
Number of Poles
4
Voltage
400 V
Nominal Voltage
25 A
Leakage Current
30 mA
with Energy Consumption Meter
No
with Timer
No
Type of Residual Current Relay
Type A

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications

Reviews (1)

Reviews

  1. 5 stars
    0
  2. 4 stars
    0
  3. 1
  4. 2 stars
    0
  5. 1 star
    0
Review this product

Reviews by our members

  • singx23
    3
    1 out of 2 members found this review helpful

    Verified purchase

    This review is about the αριθμός πόλων / ένταση: 4x63A

    The review concerns the pr8ne model. Code 500-37513. Good price for type A as well as for a Chinese product. Although the latter doesn't mean much since the use of Chinese materials by companies is now widespread.
    This particular one requires the first phase at contact 1/2 for the test button to work...
    So far, the test button only trips when phase 1/2 is present... I think that's what the diagram on it also shows...
    So if for some reason phase 1/2 drops, the other two phases at terminals 3/4 and 5/6 will continue to have power without the test button working...
    At least that's what I assume since I don't yet have a leakage tester for each phase...
    Probably the button only tests phase 1 but the protection continues to exist internally for all 3 phases...
    I still need to verify this at some point with an instrument...
    I'm not an expert, I'm just describing my observations...
    The truth is that at my house I used to have a similar relay, an old technology Siemens due to the panel's layout, four-pole and not two-pole, connected only to phase 5/6 in a single-phase supply and the leakage protection system worked fine...
    I guess it depends on the relay regarding what it allows and what not....
    Anyway, until I figured out what was going on, I did quite a bit of searching...

    Translated from Greek ·
    Did you find this review helpful?
  • The review concerns the pr8ne model. Code 500-37513. Good price for type A as well as for a Chinese product. Although the latter doesn't mean much since the use of Chinese materials by companies is now widespread.
    This particular one requires the first phase at contact 1/2 for the test button to work...
    So far, the test button only trips when phase 1/2 is present... I think that's what the diagram on it also shows...
    So if for some reason phase 1/2 drops, the other two phases at terminals 3/4 and 5/6 will continue to have power without the test button working...
    At least that's what I assume since I don't yet have a leakage tester for each phase...
    Probably the button only tests phase 1 but the protection continues to exist internally for all 3 phases...
    I still need to verify this at some point with an instrument...
    I'm not an expert, I'm just describing my observations...
    The truth is that at my house I used to have a similar relay, an old technology Siemens due to the panel's layout, four-pole and not two-pole, connected only to phase 5/6 in a single-phase supply and the leakage protection system worked fine...
    I guess it depends on the relay regarding what it allows and what not....
    Anyway, until I figured out what was going on, I did quite a bit of searching...

    Translated from Greek ·
    1
