Features:

• Power: 3000W
• Maximum Power: 9000W
• Input Voltage: (170-260) VAC 45-65Hz
• Output Voltage: AC220V±3%
• Frequency: 50/60Hz+1%
• Efficiency: >85%
• Battery Voltage: 24VDC
• DC Voltage Range: 40A
• Safety Features: Low/High Voltage, Overload, Overheating, Short Circuit
• Operating Temperature: 0ºC~ +40ºC
• Humidity: 10 - 90%

PURE SINE WAVE TRIPLE USE INVERTER CHARGER

• Battery Charger Function: Accepts 230V input from the grid (230V AC INPUT).
• Charging (e.g., AGM, GEL, Sealed or Open Type).
• UPS Function (Uninterrupted Power Supply): When receiving AC230V supply, it charges the batteries or provides power to the AC230V output. In case of interruption, it automatically switches to battery operation.
• Desulphation Function: Attempts to revive batteries that would otherwise end up in recycling.

Features:

• High efficiency
• Panel with LED indicators and adjustable selector switch
• Three-stage battery charging for increased efficiency
• Temperature protection circuit
• Fast switching for backup power
• Low power consumption (less than one Watt) that saves energy when there are no loads
• Durable construction for long life under extreme environmental conditions
• Good thermal performance up to 50°C (122°F)
• Durable, corrosion-resistant coating
• Automatic shutdown and protection in case of overvoltage
• Warning sound in case of low voltage
• Automatic shutdown and protection in case of low voltage
• Short circuit and overload protection

Inverter Operating Specifications:

• Selectable Output Voltage: 220Vac/230Vac
• Output Power: 3000W
• Starting PIC: 9000VA/10s
• Self-consumption: 0.8Ah
• Supports up to 2 horsepower motors
• Power Factor: 0-1.0
• Output Frequency: 60Hz/50Hz

Charger Operating Specifications:

• Input/Output Voltage: 220Vac/230Vac
• Charging Current: 45A
• Warranty: 2 Years

Dimensions: 44 x 20 x 18cm

Package Weight: 17kg

Available in: white or black, subject to availability
