The Series 800 is designed for serious performance.
It features:
- Cast DD basket with triple stack.
- 75 mm thick magnet.
- Long-stroke suspension.
- High-strength cone.
- Massive EROM enclosure suitable for operation in ventilated enclosures.
- 4.0" diameter aluminum coil made in the USA.
- Large 25 mm top plate.
- Headroom for extended bass performance.
- Cooling from the voice coil and motor ventilation.
Technical Specifications:
- Speaker Size: 15 Inch Power Tuned Subwoofer.
- Watts RMS: 1000-2000.
- Peak Watts: 6000.
- Impedance: D1.
- Piston Diameter: 4.
- Fs (Hz): 31.
- Qms: 4.723.
- Qes: 0.561.
- Qts: 0.501.
- Vas: 63.1.
- dBSPL: Xmech.
- Xmax (MM): 25.
- Frame OD: 15 35/64.
- Frame OD w/Gasket (MM):.
- Cut-out Diameter: 13 25/32.
- Mounting Depth: 10.
- Motor Diameter: 9 19/64.
- Motor Depth: 4 17/32.
- Magnet Weight (Oz):.
- Woofer Stiffness:.
- Ported Enclosure (CuFt): 3.0 - 5.0.
- Product Number
- 10.00.00053
- Power (RMS)
- 3000 W
- Functionality
- Passive
- with Box
- No
- Diameter
- 15 "
