General characteristics:

• 2-channel Studio microphone preamplifier
• Transformerless
• Low-cut with selectable Monitor mix
• Volume control per channel
• 20 dB pad switch
• LED Peak meter
• 2 microphone inputs: XLR
• 2 Hi-Z instrument inputs: 6.3 mm jack
• 2 line outputs: XLR
• Headphone output: 6.3 mm jack
• 19 "/ 2 U
• Handmade in Germany

Specifications:

• Frequency range 100 kHz (-3 dB @ 40 dB Gain)
• Mains Power: 100-120 V and 220-240 V; 50 Hz / 60 Hz
• Maximum power consumption 25 W
• Ground lift activation / deactivation
• Microphone inputs: 2 x XLR -3F
• Microphone inputs: Input impedance approximately 3 kΩ
• Microphone inputs: min.gain +20 dB (PAD off)
• Microphone inputs: max. gain +60 dB (PAD off)
• Microphone inputs: Attenuation PAD switchable off/ -20 dB
• Maximum input level (PAD off) +8 dBu
• Maximum input level (PAD on) +28 dBu
• EIN @ 60 dB Gain / 50 Ohm 1 -129.4 dBu (A)
• EIN @ 40 dB Gain / 50 Ohm 2 -129.2 dBu (A)
• THD Mic In @ 1kHz / 40 dB Gain / +12 dBu 3 0.00018%
• Power supply (P48, IEC 61938) 48 V, max. ? 10 mA
• Hi-Z Inputs: 2 x 6.3 mm jack (1/4 ") mono, unbalanced (front)
• Hi-Z Inputs: Input impedance 3.3 MΩ
• Hi-Z Inputs: Maximum input level +21 dBu
• Level graphs per channel -24 dBu to +24 dBu in 6 dB steps
• Bargraph Peak Hold indication @ +24 dBu (hold time approximately 3 seconds)
• Headphone output: Mono/Stereo switchable
• Volume control for left and right channel + Master
• Headphone output: Output impedance approximately 2 Ω
• Maximum output level +20 dBu at 150 Ω load impedance
• Outputs: 2 x XLR-3M
• Outputs: Maximum output level +26 dBu at 1 kΩ load impedance
• High-pass filter 60 Hz, 12 dB / octave, with activation/deactivation option
• Product dimensions (height x width x depth) 89 mm x 483 mm x 242 mm
• Weight 6.2 kg
• Operating conditions 0 ° C to + 50 ° C
• Transport/storage conditions -25 ° C to + 70 ° C
