Abb Automatic Circuit Breaker 40A Four-pole AC 24789

ABB Automatic Circuit Breaker 6.0kA C 4P 40A S204-C40.

Advantages:

  • Two different activation mechanisms: delayed thermal activation for overload protection and electromechanical mechanism for...

ABB Automatic Circuit Breaker 6.0kA C 4P 40A S204-C40.

Advantages:

  • Two different activation mechanisms: delayed thermal activation for overload protection and electromechanical mechanism for short-circuit protection.
  • Compliance with standards IEC/EN 60898-1, IEC/EN 60947-2, UL1077.
  • The auxiliary contact with the bottom can be placed on the S200 saving 50%...
See full description See full description
Review the product
Product report

Description

Description

ABB Automatic Circuit Breaker 6.0kA C 4P 40A S204-C40.

Advantages:

  • Two different activation mechanisms: delayed thermal activation for overload protection and electromechanical mechanism for short-circuit protection.
  • Compliance with standards IEC/EN 60898-1, IEC/EN 60947-2, UL1077.
  • The auxiliary contact with the bottom can be placed on the S200 saving 50% space.
  • Suitable for cable protection.
  • Circuit protection from short-circuit and overload currents.

Characteristics:

  • Curve: C
  • Rated Current: 40A
  • Frequency: 50/60Hz
  • Number of Elements-Poles: 4
  • Rated breaking capacity: 6kA
  • Overvoltage category: III
  • Cross-section of rigid cable: 0.75 ... 35 mm²
  • Cross-section of flexible cable: 0.75 ... 25 mm²
  • Operating temperature: -25 ... +55 °C
  • Protection degree: IP20
  • Dimensions: Width: 70mm, Height: 88mm, Depth: 69mm

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Specifications

Number of Poles
4
Rated Current
40 A
Operating Curve
Curve C

Operating Curve

The tripping curve shows the time required for the circuit breaker to switch off in relation to the current passing through it. For small overcurrents, the tripping is delayed to avoid unnecessary interruptions, while for very high values, such as in the case of a short circuit, the breaker operates immediately to protect the circuit. Different types of curves are used depending on the needs of each installation and the type of loads.

Curve C

The most common in general installations, ideal for circuits with motors or electronic devices.

Power Supply

AC
Yes
DC
No

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications

Description & Specifications

ABB Automatic Circuit Breaker 6.0kA C 4P 40A S204-C40.

Advantages:

  • Two different activation mechanisms: delayed thermal activation for overload protection and electromechanical mechanism for short-circuit protection.
  • Compliance with standards IEC/EN 60898-1, IEC/EN 60947-2, UL1077.
  • The auxiliary contact with the bottom can be placed on the S200 saving 50% space.
  • Suitable for cable protection.
  • Circuit protection from short-circuit and overload currents.

Characteristics:

  • Curve: C
  • Rated Current: 40A
  • Frequency: 50/60Hz
  • Number of Elements-Poles: 4
  • Rated breaking capacity: 6kA
  • Overvoltage category: III
  • Cross-section of rigid cable: 0.75 ... 35 mm²
  • Cross-section of flexible cable: 0.75 ... 25 mm²
  • Operating temperature: -25 ... +55 °C
  • Protection degree: IP20
  • Dimensions: Width: 70mm, Height: 88mm, Depth: 69mm

Manufacturer

Manufacturer Details

Warnings & Safety Information

Specifications

Number of Poles
4
Rated Current
40 A
Operating Curve
Curve C

Operating Curve

The tripping curve shows the time required for the circuit breaker to switch off in relation to the current passing through it. For small overcurrents, the tripping is delayed to avoid unnecessary interruptions, while for very high values, such as in the case of a short circuit, the breaker operates immediately to protect the circuit. Different types of curves are used depending on the needs of each installation and the type of loads.

Curve C

The most common in general installations, ideal for circuits with motors or electronic devices.

Power Supply

AC
Yes
DC
No

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
