Legrand TX3 Phase Relay Earth Leakage 40A Four-Poles with Voltage 400V 100mA
Phase Relays

Legrand TX3 Phase Relay Earth Leakage 40A Four-Poles with Voltage 400V 100mA

Residual current switch 4P 40A 0.1A Type A P304 TX3 (411775)

Description: Compliant with the EN 61008-1 standard Type A - detects sinusoidal alternating currents and pulsed direct currents.

  • Four-pole...

Residual current switch 4P 40A 0.1A Type A P304 TX3 (411775)

Description: Compliant with the EN 61008-1 standard Type A - detects sinusoidal alternating currents and pulsed direct currents.

  • Four-pole 400 V~
  • Type A
  • Nominal residual current: 100 mA
  • Nominal current: 40 A
  • Width in units 17.5 mm: 4
  • Mounting on TH35 rail
  • Connection capability with comb or pin...
See full description See full description
Review the product
Product report

Description

Description

Residual current switch 4P 40A 0.1A Type A P304 TX3 (411775)

Description: Compliant with the EN 61008-1 standard Type A - detects sinusoidal alternating currents and pulsed direct currents.

  • Four-pole 400 V~
  • Type A
  • Nominal residual current: 100 mA
  • Nominal current: 40 A
  • Width in units 17.5 mm: 4
  • Mounting on TH35 rail
  • Connection capability with comb or pin rail
  • Can be equipped with auxiliary contacts, triggers, and drive units from the DX3 series
  • Gray engagement lever
  • Number of poles: 4
  • Nominal residual current: 0.1 A
  • Ingress Protection: No available data

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Type
Earth Leakage
Number of Poles
4
Voltage
400 V
Nominal Voltage
40 A
Leakage Current
100 mA
with Energy Consumption Meter
No
with Timer
No
Type of Residual Current Relay
Type A

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications

Description & Specifications

Residual current switch 4P 40A 0.1A Type A P304 TX3 (411775)

Description: Compliant with the EN 61008-1 standard Type A - detects sinusoidal alternating currents and pulsed direct currents.

  • Four-pole 400 V~
  • Type A
  • Nominal residual current: 100 mA
  • Nominal current: 40 A
  • Width in units 17.5 mm: 4
  • Mounting on TH35 rail
  • Connection capability with comb or pin rail
  • Can be equipped with auxiliary contacts, triggers, and drive units from the DX3 series
  • Gray engagement lever
  • Number of poles: 4
  • Nominal residual current: 0.1 A
  • Ingress Protection: No available data

Manufacturer

Manufacturer Details

Warnings & Safety Information
Type
Earth Leakage
Number of Poles
4
Voltage
400 V
Nominal Voltage
40 A
Leakage Current
100 mA
with Energy Consumption Meter
No
with Timer
No
Type of Residual Current Relay
Type A

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
