Modular button 16A 1Z 1R (SVN351)

• Rated current: 16 A
• Number of modules: 1
• Number of NC contacts: 1
• Rated operating voltage Ue (AC): 230 V
• Rated insulation voltage Ui: 250 V
• Rated impulse withstand voltage Uimp: 4000 V
• Rated frequency: 50/60 Hz
• Connection type: screw connection
• Electrical endurance (Number of cycles): 15000
• Mechanical endurance (Number of cycles): 15000
• Number of wires - soldered: 0.75 / 6mm²
• Number of wires - solid: 0.75 / 10 mm²
• Operating temperature: -20 to 50 °C
• Storage temperature: -40 to 80 °C
• Height of installed product: 83 mm
• Width of installed product: 17.5 mm
• Depth of installed product: 66 mm
• Number of poles: 1
