Power Management
- Total power: 850W
- AC input voltage: 100 - 240V
- AC input frequency: 50/60Hz
- Power Factor Correction (PFC) type: Active
Combined Power
- (+3.3V): 120W
- (+12V): 850W
- (+5V): 120W
- (-12V): 3.6W
- (+5Vsb): 15W
Maximum Output Current
- (+3.3V): 22A
- (+12V): 70.8A
- (+5V): 22A
- (-12V): 0.3A
- (+5Vsb): 3A
Power Protection Features
- Over current
- Over power
- Over voltage
- Overheating
- Short circuit
- Under voltage
Connectivity
- Motherboard power connector: 20+4 pin ATX
- Peripheral (Molex) power connectors (4-pin): 4
- Motherboard power cable length: 650mm
- Number of SATA power connectors: 12
- SATA power cable length: 100, 550mm
- Peripheral (Molex) power cable length: 100, 550mm
- EPS power connector (4+4 pin): YES
- PCI Express power connectors (6+2 pin): 4
- PCI Express power cable length: 600mm
Performance
- Power supply unit (PSU) form factor: ATX
- 80 PLUS certification: 80 PLUS Gold
- Version: ATX2.3
Design
- Product color: Black
- Cooling type: Active
- Fan diameter: 140mm
- Number of fans: 1 fan(s)
- Fan locations: Top
- On/off switch: YES
Weight and Dimensions
- Width: 150mm
- Depth: 160mm
- Height: 86mm
- Weight: 2600g
Package Data
- Package weight: 3300g
Dimensions
- Power
- 850 W
- Size
- ATX
- Modularity
- Full Modular
- Certification
- 80 Plus Gold
- Fan Dimension
- 140 mm
- Power Protection
- Over Current Protection (OCP), Over Power Protection (OPP), Over Temperature Protection (OTP), Over Voltage Protection (OVP), Short Circuit Protection (SCP), Surges & Inrush Protection (SIP), Under Voltage Protection (UVP)
- Color
- Black
ATX Version
- ATX 3.1
- -
