Technical Specifications

• Design: Wall-mounted installation
• Nominal current: 160 A
• Cover type: With pre-cut holes
• Door: Single, without / closed, transparent door: no
• Material: Plastic / metal
• Color: White (RAL 9010 - Pure white)
• Finish type: Powder coating
• Dimensions:
• Depth of installed product: 193 mm
• Height of installed product: 1200 mm
• Width of installed product: 550 mm
• Width in division units: 24
• Panel material thickness: 1 mm
• Condition: Suitable for outdoor use: no
• Number of rows: 7
• Number of rails in the panel: 5
• Supports accessories: yes
• Number of openings: 2
• Expansion capability: yes
• Impact resistance: IK07
• Protection degree: IP30
• Protection class: Insulation class II
