Precision Digital to Analog Converter

Features:

• Digital Inputs: Coax S / PDIF, Optical S / PDIF, USB (Mac / PC / iOS / Android)
• Analog Outputs: XLR balanced (fixed or variable), RCA unbalanced (fixed or variable)
• Headphone Outputs: TRS unbalanced, 4-pin XLR balanced, Pentaconn balanced
• Firmware Update: Micro USB
• Input Impedance: 10 kΩ
• Output Impedance: 40 Ω
• Maximum Input Level: +23.5 dBu
• Maximum Output Level: +21.3 dBV
• Noise @ Constant Volume: -101.2 dBV typical
• Frequency Response: (5 Hz to 116 kHz): +/- 0.1 dB typical
• THD + N (@ 1 kHz): 0.0005% typical
• Unbalanced RCA Input: to Unbalanced RCA Output (2V RMS Redbook)
• Noise @ Constant Volume: -109 dBV typical
• Frequency Response: (5 Hz to 112 kHz): +/- 0.1 dB typical
• THD + N (@ 1 kHz): 0.0003% typical
• Balanced Input to Unbalanced Headphone Output: Noise @ Maximum Volume: -98.2 dBV typical
• Frequency Response: (5 Hz to 200 kHz): +/- 0.2 dB typical
• THD + N: 0.003% typical
• Digital Path Features: Coaxial S/PDIF Input to Balanced XLR Output (FIXED Volume, 192 kHz SR)
• Noise: -96.2 dBV typical
• Frequency Response: (5 Hz to 23 kHz): +/- 0.1 dB typical
• THD+N (@1 kHz): 0.0004% typical
• Coaxial S/PDIF Input to Balanced Headphone Output: Maximum output power: 1W at 16 Ω
• Noise: -89.2 dBV typical
• Frequency Response: (5 Hz to 20 kHz): +/- 0.1 dB typical
• THD + N (1W at 16 Ω): 0.008% typical
• Power Supply: Operating Mains Voltage: 100-240VAC, 50/60 Hz
• AC Power Consumption: 45W Max
