Technical Specifications LT2-E:

• Rated operating current: 0.10 to 93A
• Rated operating voltage: up to 690V AC; 50/60Hz
• Insulation voltage: >690V
• Impulse voltage withstand: 6000V
• Mechanical wear resistance (number of cycles): ≥10000000
• Electrical wear resistance (number of cycles): ≥1000000
• Ambient temperature: -10° to 65ºC
• Maximum altitude: up to 2000m

Advantages:

• Indications for activating protection
• Selection of protection recovery method
• Ability to adjust operation
• Ability to operate at higher frequency
• High reliability of current parameters
• Increased efficiency and extended operating life

Functions:

• For protection of inductive motors from overload or overheating
• To prevent motor operation under unusual temperature conditions

Applications:

• Industry
• Building construction

Mounting Method: At the terminals of the contactor and additionally tightened to the frame through a passage.

Standards: EN60947-1; EN60947-4-1; LVD; EMC
