Technical specifications:

• Functions:
• With cable entry: yes
• Electrical current:
• Rated current: 125 A
• Cover, door:
• Lock type: Folding handle with eccentric
• Cover type: With knockouts
• Door lock: None
• Door: Single
• Transparent door: no
• Materials, finish, colors:
• Color: white
• RAL color: RAL 9010 - Pure white
• Material: steel
• Surface treatment: Powder coating
• Dimensions:
• Installation depth: 112 mm
• Recess depth in wall: 115 mm
• Installed product depth: 125 mm
• Internal depth: 119 mm
• Installed product height: 853 mm
• Installation height: 853 mm
• Installed product width: 353 mm
• Width in division units: 12
• Cabinet material thickness: 1 mm
• Installation, mounting:
• Suitable for outdoor use: no
• Connection conditions:
• Number of input conductors: 2
• Equipment:
• Number of rows: 5
• Number of fields in width: 1
• Number of keys: 1
• Number of rails in the panel: 5
• Accepts accessories: yes
• Number of openings for cable entry flanges: 2
• Expansion capability: no
• Standards:
• Glow Wire Tested, made of self-extinguishing material at: 850 °C
• European WEEE directive: applicable
• Safety:
• Impact resistance IK: IK09
• Protection degree IP: IP30
• Protection class: Insulation class II
• Halogen free: no
