Voltage monitoring in single-phase network - ENYA series

• Multi-purpose
• Undervoltage monitoring
• Undervoltage monitoring with hysteresis
• Monitoring of the window between Min and Max
• Monitoring of the window between Min and Max with hysteresis
• Compatible with power relays (electrons) that receive the final load

Input characteristics

• Supply voltage: (= measurement voltage)
• Tolerance: -25% to +20% of UN
• Terminals: 230V a.c. E-F3, 24VAC E-F2, 24VDC E-F1(+)
• Nominal overvoltage: 4kV
• Overvoltage category: III (according to IEC 60664-1)

Output characteristics

• 1 changeover contact (CO)
• Switching capacity: 750VA (3A/250V AC)
• Activation delay adjustment: 0.1 - 10sec adjustable
• LED operation indicators

Technical Specifications

• Nominal Voltage: 400V
• Nominal Current: 5A
• Input Voltage: 12 - 400V AC
• Operating Temperature: -25°C / +55°C
• Mounting: DIN rail
• Mounting/Connection Method: DIN rail
• Number of DIN Elements: 1.3
• With Programming: Phase Loss, Phase Sequence, Undervoltage Control
• Type: Network Monitors
• Main Contact Type: 1 CO
• Programming Settings: 0.1s...10s
