Recording Devices

Zoom F8n Pro Polyphonic Digital Portable Recorder Battery/Power for Recording on Memory Card with Phantom Power

The Zoom F8n Pro multitrack portable recorder records up to 8 channels and 10 tracks to SD/SDHC/SDXC cards, with the ability to record simultaneously to cards and a computer via USB. 32-bit float...

The Zoom F8n Pro multitrack portable recorder records up to 8 channels and 10 tracks to SD/SDHC/SDXC cards, with the ability to record simultaneously to cards and a computer via USB. 32-bit float recording with dual A/D converters supports sample rates up to 192 kHz and requires no level adjustment. The 8 inputs combine XLR/TRS connectors and accept...

See full description See full description
The product is not available for shipping to the selected country.

Description

Description

The Zoom F8n Pro multitrack portable recorder records up to 8 channels and 10 tracks to SD/SDHC/SDXC cards, with the ability to record simultaneously to cards and a computer via USB. 32-bit float recording with dual A/D converters supports sample rates up to 192 kHz and requires no level adjustment. The 8 inputs combine XLR/TRS connectors and accept microphone- or line-level signals.

The device features microphone preamps with up to 75 dB of gain and an EIN of less than -127 dBu, as well as switchable +24 V/+48 V phantom power. It supports Ambisonics and MS decoder modes, a high-pass filter, and phase inversion. It can also be used as an 8-input/4-output USB audio interface, while the F8 Control App for iOS and Android enables wireless remote control.

Power is supplied by 8 AA batteries, a 9–18 V DC power supply via the Hirose connector, or a 12 V AC adapter. The ZOOM AD-19 power adapter is included. The aluminum housing features a 2.4-inch backlit LCD screen.

  • Type: Portable multitrack audio recorder
  • Recording channels: 8
  • Recording tracks: 10
  • Recording media: SD/SDHC/SDXC cards, up to 1 TB per card
  • Microphone inputs: 8
  • Input connectors: 8 combo XLR/TRS, with selectable microphone- or line-level signal
  • Phantom power: Switchable, +24 V or +48 V
  • Recording resolution: 32-bit float
  • Sample rate: Up to 192 kHz
  • Formats for high-definition video: 47.952/48.048 kHz
  • Microphone preamps: Up to 75 dB of gain, EIN less than -127 dBu
  • Audio features: Ambisonics, MS decoder, high-pass filter, and phase inversion
  • USB recording: Simultaneous recording to a memory card and computer
  • USB audio interface mode: 8 inputs/4 outputs
  • Timecode input and output: BNC, accuracy of 0.2 ppm during operation and up to 0.2 ppm when powered off
  • Main audio outputs: 2 balanced mini-XLR
  • Headphone output: 3.5 mm mini jack
  • Microphone compatibility: ZOOM microphone capsules
  • Remote control: Wireless via the F8 Control App for iOS and Android
  • Display: 2.4-inch backlit color LCD
  • Housing material: Aluminum
  • Power supply: 8 AA batteries, 9–18 V DC power supply via Hirose, or 12 V AC adapter
  • Package contents: ZOOM AD-19 12 V DC power adapter

Manufacturer

See full description

Specifications

Specifications

Product Details

Type
Portable
Accessory Pack
-

Technical Specifications

Channels
Multichannel
Recording to
Memory Card
Built-in Microphone
No
Microphone Inputs
8

Connections

Mini Jack (3.5mm)
No
Jack (6.3mm)
Yes
USB
Yes
XLR
Yes
RCA
No

Power Source

Phantom Power
Yes
Battery
Yes
Power
Yes
USB Power
No

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications

Description & Specifications

The Zoom F8n Pro multitrack portable recorder records up to 8 channels and 10 tracks to SD/SDHC/SDXC cards, with the ability to record simultaneously to cards and a computer via USB. 32-bit float recording with dual A/D converters supports sample rates up to 192 kHz and requires no level adjustment. The 8 inputs combine XLR/TRS connectors and accept microphone- or line-level signals.

The device features microphone preamps with up to 75 dB of gain and an EIN of less than -127 dBu, as well as switchable +24 V/+48 V phantom power. It supports Ambisonics and MS decoder modes, a high-pass filter, and phase inversion. It can also be used as an 8-input/4-output USB audio interface, while the F8 Control App for iOS and Android enables wireless remote control.

Power is supplied by 8 AA batteries, a 9–18 V DC power supply via the Hirose connector, or a 12 V AC adapter. The ZOOM AD-19 power adapter is included. The aluminum housing features a 2.4-inch backlit LCD screen.

  • Type: Portable multitrack audio recorder
  • Recording channels: 8
  • Recording tracks: 10
  • Recording media: SD/SDHC/SDXC cards, up to 1 TB per card
  • Microphone inputs: 8
  • Input connectors: 8 combo XLR/TRS, with selectable microphone- or line-level signal
  • Phantom power: Switchable, +24 V or +48 V
  • Recording resolution: 32-bit float
  • Sample rate: Up to 192 kHz
  • Formats for high-definition video: 47.952/48.048 kHz
  • Microphone preamps: Up to 75 dB of gain, EIN less than -127 dBu
  • Audio features: Ambisonics, MS decoder, high-pass filter, and phase inversion
  • USB recording: Simultaneous recording to a memory card and computer
  • USB audio interface mode: 8 inputs/4 outputs
  • Timecode input and output: BNC, accuracy of 0.2 ppm during operation and up to 0.2 ppm when powered off
  • Main audio outputs: 2 balanced mini-XLR
  • Headphone output: 3.5 mm mini jack
  • Microphone compatibility: ZOOM microphone capsules
  • Remote control: Wireless via the F8 Control App for iOS and Android
  • Display: 2.4-inch backlit color LCD
  • Housing material: Aluminum
  • Power supply: 8 AA batteries, 9–18 V DC power supply via Hirose, or 12 V AC adapter
  • Package contents: ZOOM AD-19 12 V DC power adapter
