Inverter Huawei Single-phase SUN2000 3KTL-L1

The Huawei SUN-2000-3KTL-L1 inverter allows the use of electrical energy from your photovoltaic system. The component converts direct current into alternating current, offering high efficiency to users.

Features:

• Battery connection and RS485 communication support.
• Easy integration via plug-in connections.
• Surge protection (type 2 for AC and DC).
• Two independent MPP trackers.
• Zero noise operation thanks to convection air cooling.
• Nominal power: 3,000 Watt.
• Voltage range: 90 to 560 volts.
• Operating temperature range: -25 ~ +60 °C.
• Operating relative humidity: 0% RH ~ 100% RH.
• Protection rating: IP65.

Recommended maximum PV power: 4,500 Wp.

Maximum input voltage: 600 V. Starting voltage: 100 V.

Maximum input current per MPPT: 12.5 A. Maximum short-circuit current: 18 A.

Number of MPP trackers: 2. Maximum number of inputs: 2.

AC Output:

• Network connection: single-phase.
• Nominal power: 3,000 W.
• Maximum apparent power: 3,300 VA.
• Nominal output voltage: 220 V / 230 V / 240 V.
• Maximum output current: 15 A.

Protection from:

• DC reverse polarity.
• AC overcurrent.
• AC short circuit.
• Overheating.
• Arc faults.
• DC overvoltage.
• AC overvoltage.
• DC insulation.

Compatibility with TYPE II protection according to EN / IEC 61643-11 (optional use of WLAN-FE dongle / 4G dongle).
