Technical Data

• Brand: GLOBOSTAR LED LIGHTING AND ACCESSORIES GROUP
• Series: LED BUTTONS - LED Switches
• Product Identification Code: 70770
• Category/Product Type: ON/OFF AC 230V
• Material: Inox - Stainless Steel
• Rated Voltage: AC 220..240 V
• Maximum Load Current: 5 A
• Network Frequency: 50..60 Hz
• Operating Temperature Range: -20…+55 °C
• Contact Resistance: ≤50mΩ
• Insulation Resistance: ≥1000mΩ
• Light Color: Cool White
• Protection Rating: IP67
• Rated Lifetime: 50000 h
• Number of Switching Cycles: 100000 On / Off Cycles
• Certificates & Standards: CE EMC Directive 2014/30/EU, CE LVD Directive 2014/35/EU, RoHS 2 Directive 2011/65/EU-(EU)2015/863-(EU)2017/2102
• Mercury Content: 0.0 mg
• UV / IR: 0.0 mg

Dimensions & Weight

• Diameter: Φ18mm
• Total Diameter: Φ22mm
• Cutting Hole: Φ16mm
• Weight: 11.2g
• Packaging Type: GloboStar® Label
• Quantity per Package: 1 Pc.
• Quantity per Master Package (Box): 40 Pcs.
• Package Dimensions: L100 x W50 x H20mm
• Product Weight with Packaging: 15g
• Master Package Dimensions (Box): L20.5 x W13 x H5.5cm
• Net Weight of Master Package (Box): 520g
• Volumetric Weight of Master Package (Box): 293g
• Shipping Method: By Any Means (Courier or Transport)
