The Teletek MAG4P standalone fire alarm panel supports up to 128 detectors and an unlimited number of call points. It features end-of-line (EOL) resistors for continuous input monitoring and an automatic fault diagnosis system with LED indicators. Access levels are protected by a key lock on the front of the panel, and no programming is required.

It can be connected to a dialler to transmit signals to a monitoring centre, provide fault and fire alerts, and enable remote system control via an app. It is certified to European standards EN54-2/4.

• Type: Standalone fire alarm panel
• Zones: 4
• Detector support: Up to 128
• Call point support: Unlimited number
• Sounders: Up to 4 on 2 outputs
• Input monitoring: With end-of-line (EOL) resistors
• Fault diagnosis: Automatic, with LED indicators
• Access protection: Key lock on the front panel
• Programming: Not required
• Dialler connection: Supported
• Alerts and control: Fault and fire alerts, with remote control via an app
• Certification: EN54-2/4
• Power supply: 230 VAC ± 10%, 0.63 A fuse
• Battery: 12 V / 7 Ah, not included
• Current consumption with mains power and fully charged battery: 700 mA
• Current consumption during a power outage: 50 mA
• Operating temperature: From 0 °C to +40 °C
• Weight without battery: Approx. 2.1 kg
• Dimensions: 340 × 290 × 100 mm
