• Flashlight button: Press this button briefly to turn the flashlight on/off.
• NCV Multi-Segment Display and audiovisual alarm
• True RMS/Auto backlight
• NCV/Function Hold

Specifications

• AC Current (A) 1000A ±(2%+5)
• AC Current Frequency Response 50Hz~60Hz
• AC Voltage (V) 6V ±(1.2%+3), 60V/600V/1000V ±(1%+8)
• DC Voltage (V) 600 mV ±(0.8%+3), 6V/60V ±(0.5%+5), 600V ±(0.5%+5), 1000V ±(0.5%+5)
• AC Voltage Frequency Response 40Hz~400Hz
• Resistance (Ω) 600Ω ±(1%+3), 6KΩ/60KΩ/600KΩ ±(1%+2), 6MΩ/60MΩ ±(2%+8)
• Capacitance (F) 60nF ±(4%+25), 600nF/6μF/60μF/600μF ±(4%+5), 6mF/60mF ±(10%+9)
• Low Voltage Frequency (Hz) 10Hz~1MHz ±(0.1%+3)
• Duty Cycle (%) 10%~90% ±(2.6%+7)

Features

• Display Count 6000
• Jaw Opening 42 mm
• Current Frequency 50Hz~60Hz
• High Voltage Frequency 40Hz~400Hz
• Auto Power Off
• Continuity Test
• Auto/Manual Range
• Low Battery Indicator
• Diode Test
• Relative Function/Data Hold
• Max/Min
• Function Selection
• Flashlight
• Wake-up Function
• Auto Power Off Current: ＜50μA
• Input Resistance (ACV/DCV) ≥10MΩ

General Characteristics

• Power 1.5V Battery (R03) x 3
• Display 43mm x 45mm
• Product Color Red and Grey
• Net Product Weight 465 g
• Product Size 272 mm x 81 mm x 43.5 mm
• Standard Accessories Test Leads, Batteries, Contact Point Temperature Sensor
• Standard Individual Packaging Carrying Bag, English Manual
