The KS1000-M KSN modified sine wave inverter converts 24 V DC from batteries or solar panels into 230 V AC. It provides 1000 W of continuous power and a peak power of 2000 W, and features one Schuko socket and one 5 V USB output. Its protective features cover overload, reverse battery polarity, low battery, short circuit and overheating.
It can be used to power chargers, MP3 and MP4 players, computer power supplies, laptops, tablets and game consoles, as well as TVs and DVD and CD players. It is not suitable for inductive loads, as these may damage the inverter or connected devices.
- Type: Modified sine wave
- Rated input voltage: 24 V DC
- Output voltage: 230 V AC
- Rated power: 1000 W
- Peak power: 2000 W
- Outputs: 1 Schuko socket and 1 USB 5 V
- Protections: Overload, reverse battery polarity, low battery, short circuit and overheating
- Fan: 1
- Self-consumption: 0.32 A at 24 V DC
- Dimensions: 21 × 15 × 7 cm
- Standards and certifications: EN55032, EN50581, EN62368-1, ISO9001/IATF16949/BSCI
- Type
- Modified Sine Wave
- Rated power
- 1000 W
- Nominal Input Voltage
- 24 V
