Deepcool CH510 Gaming Midi Tower Computer Case with Side Window Mesh Digital

Name: Deepcool CH510 Gaming Midi Tower Computer Case with Side Window Mesh Digital
Brand: Deepcool
SKU: 39861347
Rating: 4.2 (6 reviews)

Design

Form factor: Midi Tower
Type: PC
Product color: Black
Supported motherboard form factors: ATX, EATX, Micro ATX, Mini-ATX
Number of 3.5" bays: 2
Material: Acrylonitrile Butadiene Styrene (ABS),...

Design

Form factor: Midi Tower
Type: PC
Product color: Black
Supported motherboard form factors: ATX, EATX, Micro ATX, Mini-ATX
Number of 3.5" bays: 2
Material: Acrylonitrile Butadiene Styrene (ABS), SPCC, Tempered glass
Number of 2.5" bays: 3
Number of expansion slots: 7
Side window: YES
Tempered glass panel(s): YES
LED indicators: Power
Maximum CPU cooler...

See full description See full description

Internal 3.5'' Bays

Installation locations for hard drives of corresponding size (usually HDD).
Internal Ports 2.5''

Installation locations for hard disks of corresponding size (usually SSDs).
Connectivity

Audio

Port for connecting headphones or speakers with a cable.

USB 3.0

Faster data transfer (5 Gbit/s) than USB 2.0. Compatible with older versions. Also referred to as USB 3.1 Gen 1 / 3.2 Gen 1.
Add-ons

Side Window

It has a side window to make the interior visible without opening the case.
See all

The product is not available at Skroutz Last updated: about 1 month ago

Description

Design

Form factor: Midi Tower
Type: PC
Product color: Black
Supported motherboard form factors: ATX, EATX, Micro ATX, Mini-ATX
Number of 3.5" bays: 2
Material: Acrylonitrile Butadiene Styrene (ABS), SPCC, Tempered glass
Number of 2.5" bays: 3
Number of expansion slots: 7
Side window: YES
Tempered glass panel(s): YES
LED indicators: Power
Maximum CPU cooler height: 175mm
Maximum graphics card length: 380mm
Maximum PSU length: 170mm
Supported power supply form factors: ATX, PS2
Number of USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports: 1
Number of USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports: 1
Maximum front fans: 3
Installed rear fans: 1x 120 mm
Maximum rear fans: 1
Maximum top fans: 3
Supported front fan sizes: 120, 140, 240, 280, 360mm
Supported rear fan sizes: 120, 140mm
Supported top fan sizes: 120, 140, 240, 280, 360mm
Supported hard drive sizes: 2.5, 3.5"
Width: 230mm
Depth: 455mm
Height: 470mm
Weight: 7500g

Manufacturer

Deepcool - Computer Cases Deepcool

See full description

Specifications

Main Specifications

Colour: Black

Size: Midi Tower

Compatible Motherboard Type: ATX, -, Extended ATX, Micro ATX, Mini ITX

Dimensions

Height: 470 mm

Width: 230 mm

Length: 455 mm

Internal Spaces

Maximum Graphics Card Length: 380 mm

Maximum Processor Heatsink Height: 175 mm

Drive Bays

Internal Hub 3.5": 2

Internal Hub 2.5": 2

Fan Positions

Front: 3

Rear: 1

Top Positions: 3

Water Cooling

Radiator Position: Top, Front, Back

Specifications

Connectivity: Audio, USB 3.0

Extras: Side Window

Gaming: Yes

Airflow: Yes

Home & Office: No

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications

Reviews (6)

Reviews

4.2

4.2

Review this product

4
1
3 stars

0
2 stars

0
1

Review this product

Space
Cable management
Air flow
Silent
Value for money
Dust filtering
Construction quality

Reviews photos

5

1 out of 1 members found this review helpful

Vlx_Jim
2025-01-12
The case is simply perfect. Whatever dreams you have about space, airflow, and beauty. I have installed a total of 8 fans (+2 on the cooler) and I can hardly hear anything (with a little adjustment) and there is still space left. In terms of cable management, it also doesn't fall behind; it has plenty of space for unnecessary cables and for HDD drives (the SSDs have two slots in the middle of the case at the back, very convenient) and the fact that it costs around €85 and with a little screen it's even better, and it is also accurate, showing exactly what the temperatures are

Translated from Greek ·
- Space
- Cable management
- Construction quality
- Silent
- Dust filtering
- Air flow
- Value for money
Did you find this review helpful?
1

2 out of 3 members found this review helpful

VASILEIOS_RAFAILIDIS
2024-03-15
This review is about a variation of the product

Not a good box at all, the paint cracked even though it was on thick cardboard and it started to come off from the bottom as well, I do not recommend it

Translated from Greek ·
- Space
- Cable management
- Silent
- Dust filtering
- Air flow
- Construction quality
- Value for money
Did you find this review helpful?
4

Dimitris_Ps
2023-12-16
In search of a box that wouldn't be ugly, large, and at a reasonable price, everything I ordered in the end was canceled. After 1 month of searching, the only available one in a store near me was this one.
The review is about the ch510 mesh digital.
It is the most beautiful compared to the ugliness that circulates up to 80 euros and the screen, although small, gives style. It comes with a mediocre fan.
Final price with an additional 5 montech metal fans is 130 euros (Excellent fans, quiet and powerful).
The cable management is very easy.
Installed:
- 3 montech fans for hot air extraction, 2 on top and 1 at the back.
- 2 montech fans for cold air intake at the front.
- 1 factory fan at the bottom.*
In a stress test, the Ryzen 5600 with the factory cooler (replaced the factory paste with mx-4), without dust filters, reaches 70 degrees with the fans at 50%.

*It can fit 2 fans at the bottom, but if you connect the usb3 cable from the front panel, which is very thick, one of the two fans becomes useless. The solution I found is to screw it from the bottom, behind the power supply. This way, it can easily pull air from the mesh on the sides. It requires large liquid cooling screws. There are such screws in the box, but they didn't fit from the bottom. Luckily, the ones that montech provided with each fan fit perfectly.

Translated from Greek ·
- Space
- Cable management
- Air flow
- Value for money
- Construction quality
- Moderate noise
- Dust filtering
Did you find this review helpful?
5

Giorgos_Tsilikis90
2024-07-09

Verified purchase
- Space
- Cable management
- Construction quality
- Dust filtering
- Air flow
- Value for money
5

stergiosdjohn
2023-05-09

Verified purchase
- Space
- Cable management
- Construction quality
- Silent
- Dust filtering
- Air flow
- Value for money
5

Simon_Zampethanis
2023-04-26

Verified purchase
- Space
- Cable management
- Construction quality
- Silent
- Air flow
- Value for money

5

Vlx_Jim
2025-01-12

The case is simply perfect. Whatever dreams you have about space, airflow, and beauty. I have installed a total of 8 fans (+2 on the cooler) and I can hardly hear anything (with a little adjustment) and there is still space left. In terms of cable management, it also doesn't fall behind; it has plenty of space for unnecessary cables and for HDD drives (the SSDs have two slots in the middle of the case at the back, very convenient) and the fact that it costs around €85 and with a little screen it's even better, and it is also accurate, showing exactly what the temperatures are

Translated from Greek ·

1
1

VASILEIOS_RAFAILIDIS
2024-03-15

Not a good box at all, the paint cracked even though it was on thick cardboard and it started to come off from the bottom as well, I do not recommend it

Translated from Greek ·

2
4

Dimitris_Ps
2023-12-16

In search of a box that wouldn't be ugly, large, and at a reasonable price, everything I ordered in the end was canceled. After 1 month of searching, the only available one in a store near me was this one.
The review is about the ch510 mesh digital.
It is the most beautiful compared to the ugliness that circulates up to 80 euros and the screen, although small, gives style. It comes with a mediocre fan.
Final price with an additional 5 montech metal fans is 130 euros (Excellent fans, quiet and powerful).
The cable management is very easy.
Installed:
- 3 montech fans for hot air extraction, 2 on top and 1 at the back.
- 2 montech fans for cold air intake at the front.
- 1 factory fan at the bottom.*
In a stress test, the Ryzen 5600 with the factory cooler (replaced the factory paste with mx-4), without dust filters, reaches 70 degrees with the fans at 50%.

*It can fit 2 fans at the bottom, but if you connect the usb3 cable from the front panel, which is very thick, one of the two fans becomes useless. The solution I found is to screw it from the bottom, behind the power supply. This way, it can easily pull air from the mesh on the sides. It requires large liquid cooling screws. There are such screws in the box, but they didn't fit from the bottom. Luckily, the ones that montech provided with each fan fit perfectly.

Translated from Greek ·

0
5

Giorgos_Tsilikis90
2024-07-09

0
5

stergiosdjohn
2023-05-09

0
