DC-AC inverter 350VA/24V with sinusoidal output. Instantaneous start-up load 700W. Efficiency rating 90%. Connection with MT91 LCD screen and computer or mobile phone. Energy-saving mode.

The IPT series is a high-frequency pure sine wave DC/AC inverter. It is designed with a fully digital smart design and a dual closed-loop current voltage control algorithm.

• Fast response
• High conversion efficiency
• Low total harmonic distortion (THD)
• High reliability in operation

This series can be widely used in off-grid DC-AC systems, such as:

• Vehicle systems
• Security monitoring systems
• Emergency lighting systems
• Home power systems
• Field power supply systems
• Other systems requiring higher power quality

Warning: The AC neutral should not be grounded.

Technical Specifications:

• Continuous power: 350W@35°C@Rated input voltage
• Peak power: 700W@5S
• Input voltage: 24VDC 21.6 ~ 32VDC
• Output voltage: 220VAC (±3%); 230VAC (-7%~+3%), 50/60Hz ± 0.2%, Pure Sine Wave
• Maximum output efficiency: > 91.5% (70% loads)
• Harmonic distortion: THD
