Power Management

• Total Capacity: 450W
• AC Input Voltage: 100 - 240V
• AC Input Frequency: 47 - 63Hz
• Power Factor Correction (PFC) Type: Active
• Combined Capacity (+3.3V): 150W
• Combined Capacity (+5V): 150W
• Combined Capacity (-12V): 25W
• Combined Capacity (+5Vsb): 25W
• Maximum Output Current (+3.3V): 30A
• Maximum Output Current (+12V1): 20A
• Maximum Output Current (+12V2): 20A
• Maximum Output Current (-12V): 1A
• Maximum Output Current (+5Vsb): 3A
• Backup Power Capacity: YES
• Protection Features: Over current, Over voltage, Overload, Short circuit

Connectivity

• Motherboard Power Connector: 24-pin ATX
• Peripheral (Molex) Connectors (4 pins): 2
• Number of SATA Power Connectors: 6
• Processor Power Connector (4+4 pins): YES
• ATX Power Connector (24-pin): YES
• Floppy Drive Power Connector: 1

Performance

• Purpose: Server
• 80 PLUS Certification: 80 PLUS Silver
• MTBF Rate: 100000h

Design

• Product Color: Silver
• Cooling Type: Active
• Fan Diameter: 40mm
• Number of Fans: 4
• Power On/Off Switch: YES

Weight and Dimensions

• Width: 150mm
• Depth: 190mm
• Height: 84mm
• Weight: 3710g
