The Behringer PMP6000 powered analog mixer combines a 20-channel mixer with a Class-D stereo amplifier delivering 2 x 800 W or 1,600 W in bridged mode. The mixer section includes 12 mono and 4 stereo channels, as well as separate CD/Tape input and output. The 12 XENYX microphone preamps support +48 V phantom power for condenser microphones.

The two 24-bit stereo Multi-FX processors provide 100 presets, including reverb, chorus, flanger, delay, and pitch shifter. The FBQ system detects critical frequencies for easier feedback filtering, while the 7-band stereo graphic EQ lets you adjust frequencies on the monitor or main outputs. The mixer also features Voice Canceller, XPQ 3D stereo surround, and Speaker Processing functions.

• Type: Powered analog mixer
• Channels: 20, with 12 mono and 4 stereo
• Amplifier power: 2 x 800 W stereo or 1,600 W in bridged mode
• Amplifier technology: Class-D
• XLR inputs: 12
• Microphone preamps: 12 XENYX
• Phantom power: +48 V
• Effects processors: 2 stereo 24-bit Multi-FX
• Effects presets: 100, including reverb, chorus, flanger, delay, and pitch shifter
• Equalizer: 3-band on mono channels and 7-band stereo graphic
• Low Cut filter: On mono channels
• Feedback detection system: FBQ
• Functions: Voice Canceller, Speaker Processing, and XPQ 3D stereo surround
• Amplifier modes: Stereo, dual mono, or bridged mono
• 2-Track input: Adjustable stereo, RCA type
• CD/Tape input/output: Separate
• Preamp outputs: Stereo, for main and monitor
• Headphone jack: Yes
• Indicators: Clip LEDs on mono channels and 2-digit LED display
• Power supply: Internal switch-mode
• Height: 122 mm
• Length: 596 mm
• Depth: 496 mm
• Weight: 13.1 kg
