Manufacturer: GEBERIT

Series: DUOFIX

Product Code: 111.170.00.1

Geberit Duofix support element for wall-hung toilet bowls, with concealed Delta cistern, includes:

• Maximum water temperature: 25 °C
• Factory water volume settings for 6 l
• Large flush volume adjustment range: 4.5 / 6 / 7.5 l
• Adjustment range for small flush
• Lightweight installation and wall mounting
• For wall-hung toilet bowls with connection dimensions according to EN 33:2011
• Single flush, dual flush, or "stop" function
• Self-supporting frame with powder coating
• Frame with drilled hole ø 9 mm for wooden structures
• Galvanized assembly feet with adjustable position 0-20 cm
• Plastic feet
• Foot depth suitable for U UW 50 profile
• Water connection at the back or top in the middle
• Equipped with a protective pipe for quick water connection
• Flow pressure range: 0.1-10 bar
• Water connection R 1/2", compatible with MeplaFix adapter
