Dimensions

Type

TIG, MMA

Type

TIG

Slow welding for detailed work on aluminum and stainless steel, mainly. Requires experience and connection to an external gas cylinder. Does not create "spatters".

MMA

Creates thick and strong bonds without the need for external gas supply, making it ideal for out-of-lab welding.

Welding Current (max)

180 A

Welding Current (max): 180

Suitable for use in medium-thickness metal constructions and pipelines.

Operation Cycle (max Ampere)

60 %

Operation Cycle (max Ampere)

The Duty Cycle is the portion of a ten-minute period that a welding machine can operate continuously at maximum Amperes before it needs to stop and cool down.

2.

For example, a welding machine with a maximum Amperage of 200 A and a Duty Cycle of 30% can operate continuously at 200 A for 3 minutes before it needs to stop.

Supply Voltage

220 V

Supply Voltage: 220

It is the supply voltage that the machine requires from the electrical grid.

Maximum Electrode Diameter

5 mm

Maximum Electrode Diameter: 5

The maximum electrode thickness that the machine can support, depending on the maximum current it can provide.

Weight

3500 gr

Additional Features

Inverter

Yes

Inverter

New technology welding. Very good in terms of performance, durability, and weight, but with a high cost of repair in case of damage. They have automation for better and safer work. If connected to a generator, it is recommended to choose one with 8kVA or more.

IGBT

Yes

IGBT

Allows the conversion of direct current (DC) voltage to alternating current (AC) or the output of direct current at a higher or lower intensity.

VRD

No

with Voltage Stabilizer

No

for Generator with AVR

No

Features

Hot Start

Yes

Hot Start

Temporarily increases the current intensity at the moment of welding initiation.

Anti Stick

No

Arc Force

Yes

Arc Force

Helps in the stability of the arc during welding.

2T Operation

No

4T Mode

No

Spot Function

No

Pulsed

No
