MPC Swing Garage Door Motor up to 300kg 2XMPC-400-SOLO
Garage Door Motors

MPC Swing Garage Door Motor up to 300kg 2XMPC-400-SOLO

Swing garage door motor by MPC company. It is flexible and practical in spaces with enough depth for the opening of the leaves. Supports garage doors with a maximum weight of up to 300kg.

Swing garage door motor by MPC company. It is flexible and practical in spaces with enough depth for the opening of the leaves. Supports garage doors with a maximum weight of up to 300kg.

See full description See full description
Review the product
Product report

Description

Description

Swing garage door motor by MPC company. It is flexible and practical in spaces with enough depth for the opening of the leaves. Supports garage doors with a maximum weight of up to 300kg.

Features

  • Ideal for swing iron gates - garage doors - garden gates up to 300 kg, & 1.8 m
  • The motor is of closed type, with an electromechanical screw which ensures
  • trouble-free operation in all conditions.
  • It features a built-in thermal protector for the motor. Manual operation with key.

Specifications

  • Operating voltage of motor engine : 230 VAC
  • Power consumption : 280 W
  • Maximum leaf length : 1.8 m
  • For blind door leaves : Use of electric lock is recommended.
  • Maximum usage frequency : 35% (12 Cycles/Hour 20 Cycles/Day)
  • Operating temperature : -20°C to +70°C
  • Type : Non-reversible electromechanical mechanism
  • with worm gear.
  • Body material : Aluminum
  • Piston speed : 1.8 cm/sec
  • Maximum thrust : 300 daN
  • Protection rating against dust and moisture : IP-44
  • Motor speed : 1,400 rpm
  • Operating current intensity : 1.8 A
  • Motor winding thermal protection : 150°C
  • Manual disengagement : With special key.
  • Useful piston stroke : 400 mm
  • Mechanism dimensions : Closed 770 Open 1130 mm
  • Mechanism weight : 2x 6 Kg
  • Warranty : 2 Years for the Motor, 5 Years for the Control Panel etc.

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Type
Counterweight

Type

Counterweight
It is flexible and practical in spaces that have enough depth to open their leaves.
Maximum Weight
300 kg

Maximum Weight

Describes the maximum weight of the garage door that is suitable for the motor.

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications

Description & Specifications

Swing garage door motor by MPC company. It is flexible and practical in spaces with enough depth for the opening of the leaves. Supports garage doors with a maximum weight of up to 300kg.

Features

  • Ideal for swing iron gates - garage doors - garden gates up to 300 kg, & 1.8 m
  • The motor is of closed type, with an electromechanical screw which ensures
  • trouble-free operation in all conditions.
  • It features a built-in thermal protector for the motor. Manual operation with key.

Specifications

  • Operating voltage of motor engine : 230 VAC
  • Power consumption : 280 W
  • Maximum leaf length : 1.8 m
  • For blind door leaves : Use of electric lock is recommended.
  • Maximum usage frequency : 35% (12 Cycles/Hour 20 Cycles/Day)
  • Operating temperature : -20°C to +70°C
  • Type : Non-reversible electromechanical mechanism
  • with worm gear.
  • Body material : Aluminum
  • Piston speed : 1.8 cm/sec
  • Maximum thrust : 300 daN
  • Protection rating against dust and moisture : IP-44
  • Motor speed : 1,400 rpm
  • Operating current intensity : 1.8 A
  • Motor winding thermal protection : 150°C
  • Manual disengagement : With special key.
  • Useful piston stroke : 400 mm
  • Mechanism dimensions : Closed 770 Open 1130 mm
  • Mechanism weight : 2x 6 Kg
  • Warranty : 2 Years for the Motor, 5 Years for the Control Panel etc.

Manufacturer

Manufacturer Details

Warnings & Safety Information
Type
Counterweight

Type

Counterweight
It is flexible and practical in spaces that have enough depth to open their leaves.
Maximum Weight
300 kg

Maximum Weight

Describes the maximum weight of the garage door that is suitable for the motor.

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
