Pure Sine Wave DC-AC Inverter

Using 24VDC or 12VDC batteries, the Inverters convert direct current to alternating current in a pure sine wave form, with a voltage of 230VAC, suitable for powering all kinds of loads.

To correctly choose the power, the maximum consumption currents for each device must be calculated, such as starting currents for inductive loads, laser printers, etc.

Applications:

• Vehicles and motorhomes
• Camping and boats
• Photovoltaic systems
• Wind turbine systems
• Telecommunication stations
• Suitable for inductive loads (refrigerators, drills, etc.)

Technical Specifications:

• Power: 3000W
• Maximum power: 6000W
• Input voltage: 12VDC
• Output voltage: 230VAC, 50Hz
• High-efficiency pure sine wave output
• Self-consumption: 1.26A (12VDC) / 1.22A (24VDC)
• 2 schuko sockets
• 1 fan
• Certifications: EN55032, EN50581, EN62368-1, ISO9001/IATF16949/BSCI
• Dimensions: 36x22x15cm
