Pure Sine Wave DC-AC Inverter

Using 24VDC or 12VDC batteries, the Inverters convert direct current to alternating current, pure sine wave form, 230VAC voltage, suitable to power all kinds of loads.

For the correct power selection, the maximum consumption currents per device should be calculated, such as starting currents of inductive loads, laser printers, etc.

Applications:

• Vehicles and caravans
• Camping and boats
• Photovoltaic systems
• Wind turbine systems
• Telecommunication stations, etc.
• Suitable for inductive loads (refrigerators, drills, etc.)

Properties:

• Power: 1000W
• Maximum power: 2000W
• Input voltage: 24VDC
• Output voltage: 230VAC, 50Hz
• High-efficiency pure sine wave output
• Self-consumption: 0.73A (12VDC) / 0.71A (24VDC)
• 1 Schuko socket
• 1 fan
• EN55032, EN50581, EN62368-1, ISO9001/IATF16949/BSCI
• Dimensions: 31x15x7cm
