Optex SL-200-QDP Wired Four-Beam Detector IP65 10.5-30V Scope 60m
Beam Sensors

Optex SL-200-QDP Wired Four-Beam Detector IP65 10.5-30V Scope 60m

  • Type: Photoelectric beam detector with 4 beams (Quad Beam)
  • Range: 60 meters (outdoor)
  • Operating voltage: 10.5 - 30V DC
  • Total power consumption: 24mA
  • Operating temperature: -35°C to +60°C
  • Technology: Double...
  • Type: Photoelectric beam detector with 4 beams (Quad Beam)
  • Range: 60 meters (outdoor)
  • Operating voltage: 10.5 - 30V DC
  • Total power consumption: 24mA
  • Operating temperature: -35°C to +60°C
  • Technology: Double modulation (dual modulation to prevent interference)
  • Design: Slim
  • Waterproof: IP65 (full dust and water protection)
  • Anti-freeze protection: Special design for...
See full description See full description

  • Login

    Wired

    It connects to the installation system with a cable and is powered through it.

  • Number of Beams

    The number of beams indicates the quantity of infrared rays connecting the transmitter to the receiver. More beams mean greater coverage height and fewer false alarms, as all beams must be interrupted simultaneously to trigger the system.

  • Range

    The range indicates the maximum distance (in meters) that the transmitter can be from the receiver in order to operate reliably.

  • Length

    Usually, the greater the length, the more beams there are in the device, and therefore the greater the coverage length of the detector.

  • Operating Voltage

    It refers to wired beam detectors and indicates how much voltage (in Volts) the detector needs to operate.

  • Number of Channels

    The number of channels indicates the different frequencies that the detector can use. It allows the installation of multiple pairs in the same area without interference between them, ensuring that each receiver "listens" only to its own transmitter.

  • Protection Certification

    IP65

    Suitable for outdoor areas with heavy rain or pressurized water. Provides complete protection against dust and object intrusion, ideal for gardens or industrial spaces.
  • See all
Review the product
Product report

Description

Description

  • Type: Photoelectric beam detector with 4 beams (Quad Beam)
  • Range: 60 meters (outdoor)
  • Operating voltage: 10.5 - 30V DC
  • Total power consumption: 24mA
  • Operating temperature: -35°C to +60°C
  • Technology: Double modulation (dual modulation to prevent interference)
  • Design: Slim
  • Waterproof: IP65 (full dust and water protection)
  • Anti-freeze protection: Special design for extreme cold
  • Easy adjustment: Special reflector and bright internal body color
  • Security: Equipped with Tamper protection on transmitter and receiver
  • Dimensions: 48mm (Width) x 79mm (Depth) x 96mm (Height)

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Connector
Wired

Connector

Wired
It connects to the installation system with a cable and is powered through it.
Scope
60 m

Scope

The range indicates the maximum distance (in meters) that the transmitter can be from the receiver in order to operate reliably.
Number of Beams
4 Bundles

Number of Beams

The number of beams indicates the quantity of infrared rays connecting the transmitter to the receiver. More beams mean greater coverage height and fewer false alarms, as all beams must be interrupted simultaneously to trigger the system.
Operating Voltage
10.5-30V

Operating Voltage

It refers to wired beam detectors and indicates how much voltage (in Volts) the detector needs to operate.
Number of Channels
4

Number of Channels

The number of channels indicates the different frequencies that the detector can use. It allows the installation of multiple pairs in the same area without interference between them, ensuring that each receiver "listens" only to its own transmitter.
Protection Certification
IP65

Protection Certification

IP65
Suitable for outdoor areas with heavy rain or pressurized water. Provides complete protection against dust and object intrusion, ideal for gardens or industrial spaces.
Length
9.6 cm

Length

Usually, the greater the length, the more beams there are in the device, and therefore the greater the coverage length of the detector.

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications

Description & Specifications

  • Type: Photoelectric beam detector with 4 beams (Quad Beam)
  • Range: 60 meters (outdoor)
  • Operating voltage: 10.5 - 30V DC
  • Total power consumption: 24mA
  • Operating temperature: -35°C to +60°C
  • Technology: Double modulation (dual modulation to prevent interference)
  • Design: Slim
  • Waterproof: IP65 (full dust and water protection)
  • Anti-freeze protection: Special design for extreme cold
  • Easy adjustment: Special reflector and bright internal body color
  • Security: Equipped with Tamper protection on transmitter and receiver
  • Dimensions: 48mm (Width) x 79mm (Depth) x 96mm (Height)

Manufacturer

Manufacturer Details

Warnings & Safety Information
Connector
Wired

Connector

Wired
It connects to the installation system with a cable and is powered through it.
Scope
60 m

Scope

The range indicates the maximum distance (in meters) that the transmitter can be from the receiver in order to operate reliably.
Number of Beams
4 Bundles

Number of Beams

The number of beams indicates the quantity of infrared rays connecting the transmitter to the receiver. More beams mean greater coverage height and fewer false alarms, as all beams must be interrupted simultaneously to trigger the system.
Operating Voltage
10.5-30V

Operating Voltage

It refers to wired beam detectors and indicates how much voltage (in Volts) the detector needs to operate.
Number of Channels
4

Number of Channels

The number of channels indicates the different frequencies that the detector can use. It allows the installation of multiple pairs in the same area without interference between them, ensuring that each receiver "listens" only to its own transmitter.
Protection Certification
IP65

Protection Certification

IP65
Suitable for outdoor areas with heavy rain or pressurized water. Provides complete protection against dust and object intrusion, ideal for gardens or industrial spaces.
Length
9.6 cm

Length

Usually, the greater the length, the more beams there are in the device, and therefore the greater the coverage length of the detector.

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
