Applications in holiday homes, boats, photovoltaic systems.
- Blade material: Carbon fiber
- Frame material: Aluminum
- Power: 400 Watts
- Voltage: 12 Volts
- Blade diameter: 1.2m
- Blade length: 60cm
- Minimum wind speed for operation: 2.5m/sec (2 Beaufort)
- Optimal wind speed for operation: 12m/sec (6 Beaufort)
- Maximum allowable wind speed: 40m/sec (12 Beaufort)
- Wind direction tracking system: Mechanical
- Rotation speed: 400-450rpm
- Generator operation method: Magnetic saturation
- Net weight of the wind turbine: 6.5KG
- Temperature operation range: -45°C to 70°C
- Lifespan: 15 years
Note: The wind turbine operates in systems with a nominal battery voltage of 12V. The battery must be connected first to the charge controller to recognize the voltage, and then the wind turbine can be connected.
Includes:
- 1 generator
- 1 external MPPT charge controller
- 3 blades
