Endorfy Supremo FM5 650W Black Computer Power Supply Full Modular 80 Plus Gold
Power Supplies

Endorfy Supremo FM5 650W Black Computer Power Supply Full Modular 80 Plus Gold

ENDORFY Supremo FM5

  • Total power: 650 W
  • AC input voltage: 115 - 230 V
  • AC input frequency: 50/60 Hz
  • Motherboard power connector: 18+10 pin ATX
  • Cable type: Modular
  • Purpose: PC
  • Power supply unit (PSU)...

ENDORFY Supremo FM5

  • Total power: 650 W
  • AC input voltage: 115 - 230 V
  • AC input frequency: 50/60 Hz
  • Motherboard power connector: 18+10 pin ATX
  • Cable type: Modular
  • Purpose: PC
  • Power supply unit (PSU) form factor: ATX
  • 80 PLUS certification: 80 PLUS Gold
  • Product color: Black
  • Fan diameter: 12 cm
  • Number of fans: 1
  • Combined power (+3.3V): 100W
  • Combined power...
See full description See full description

  • Type

    Specifies the size and compatibility with the computer case. The most common types are ATX for standard cases, SFX and TFX for small or slim systems, and EPS for powerful setups or servers.

    ATX

    The most common power supply size, compatible with most mid and full tower cases.
  • Certification 80 Plus Gold

  • Fan Dimension

    The diameter of the fan in millimeters. The larger the fan, the more effective the cooling and the quieter the power supply operation. The most common size is 120mm, with some power supplies reaching up to 140mm.
  • See all
Review the product
Product report

Description

Description

ENDORFY Supremo FM5

  • Total power: 650 W
  • AC input voltage: 115 - 230 V
  • AC input frequency: 50/60 Hz
  • Motherboard power connector: 18+10 pin ATX
  • Cable type: Modular
  • Purpose: PC
  • Power supply unit (PSU) form factor: ATX
  • 80 PLUS certification: 80 PLUS Gold
  • Product color: Black
  • Fan diameter: 12 cm
  • Number of fans: 1
  • Combined power (+3.3V): 100W
  • Combined power (+12V): 648W
  • Combined power (+5V): 100W
  • Combined power (-12V): 3.6W
  • Combined power (+5Vsb): 15W
  • Maximum output current (+3.3V): 20A
  • Maximum output current (+12V): 54A
  • Maximum output current (+5V): 20A
  • Maximum output current (-12V): 0.3A
  • Maximum output current (+5Vsb): 3A
  • Power protection features: Over current, Over power, Over voltage, Short circuit, Under voltage
  • Number of SATA power connectors: 3
  • PCI Express power connectors (8-pin): 6
  • MTBF rate: 100000h

Dimensions

  • Width: 140mm
  • Depth: 150mm
  • Height: 87mm

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Dimensions

Power
650 W
Size
ATX

Size

Specifies the size and compatibility with the computer case. The most common types are ATX for standard cases, SFX and TFX for small or slim systems, and EPS for powerful setups or servers.

ATX
The most common power supply size, compatible with most mid and full tower cases.
Modularity
Full Modular

Modularity

Describes the degree to which power cables are detachable. Modular power supplies allow for the use of only necessary cables, resulting in better aesthetics and airflow.

Full Modular

All cables are detachable from the power supply. It helps for a more organized assembly with better aesthetics and airflow.
Certification
80 Plus Gold
Fan Dimension
120 mm

Fan Dimension

The diameter of the fan in millimeters. The larger the fan, the more effective the cooling and the quieter the power supply operation. The most common size is 120mm, with some power supplies reaching up to 140mm.
Power Protection
Over Current Protection (OCP), Over Power Protection (OPP), Over Temperature Protection (OTP), Over Voltage Protection (OVP), Surges & Inrush Protection (SIP), Under Voltage Protection (UVP)

Power Protection

The various types of protection that the power supply has.

Over Current Protection (OCP)

Protects connected devices from excessive current intensity.

Over Power Protection (OPP)
Protects the power supply if its nominal power is exceeded.
Over Temperature Protection (OTP)
Protects the power supply from overheating.
Over Voltage Protection (OVP)

Protects connected devices from excessive voltage.

Surges & Inrush Protection (SIP)
Protects the power supply during connection to the socket and from strong network fluctuations.
Under Voltage Protection (UVP)

Protects connected devices from low voltage current.
Color
Black

ATX Version

ATX 3.1
-

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications

Description & Specifications

ENDORFY Supremo FM5

  • Total power: 650 W
  • AC input voltage: 115 - 230 V
  • AC input frequency: 50/60 Hz
  • Motherboard power connector: 18+10 pin ATX
  • Cable type: Modular
  • Purpose: PC
  • Power supply unit (PSU) form factor: ATX
  • 80 PLUS certification: 80 PLUS Gold
  • Product color: Black
  • Fan diameter: 12 cm
  • Number of fans: 1
  • Combined power (+3.3V): 100W
  • Combined power (+12V): 648W
  • Combined power (+5V): 100W
  • Combined power (-12V): 3.6W
  • Combined power (+5Vsb): 15W
  • Maximum output current (+3.3V): 20A
  • Maximum output current (+12V): 54A
  • Maximum output current (+5V): 20A
  • Maximum output current (-12V): 0.3A
  • Maximum output current (+5Vsb): 3A
  • Power protection features: Over current, Over power, Over voltage, Short circuit, Under voltage
  • Number of SATA power connectors: 3
  • PCI Express power connectors (8-pin): 6
  • MTBF rate: 100000h

Dimensions

  • Width: 140mm
  • Depth: 150mm
  • Height: 87mm

Manufacturer

Manufacturer Details

Warnings & Safety Information

Dimensions

Power
650 W
Size
ATX

Size

Specifies the size and compatibility with the computer case. The most common types are ATX for standard cases, SFX and TFX for small or slim systems, and EPS for powerful setups or servers.

ATX
The most common power supply size, compatible with most mid and full tower cases.
Modularity
Full Modular

Modularity

Describes the degree to which power cables are detachable. Modular power supplies allow for the use of only necessary cables, resulting in better aesthetics and airflow.

Full Modular

All cables are detachable from the power supply. It helps for a more organized assembly with better aesthetics and airflow.
Certification
80 Plus Gold
Fan Dimension
120 mm

Fan Dimension

The diameter of the fan in millimeters. The larger the fan, the more effective the cooling and the quieter the power supply operation. The most common size is 120mm, with some power supplies reaching up to 140mm.
Power Protection
Over Current Protection (OCP), Over Power Protection (OPP), Over Temperature Protection (OTP), Over Voltage Protection (OVP), Surges & Inrush Protection (SIP), Under Voltage Protection (UVP)

Power Protection

The various types of protection that the power supply has.

Over Current Protection (OCP)

Protects connected devices from excessive current intensity.

Over Power Protection (OPP)
Protects the power supply if its nominal power is exceeded.
Over Temperature Protection (OTP)
Protects the power supply from overheating.
Over Voltage Protection (OVP)

Protects connected devices from excessive voltage.

Surges & Inrush Protection (SIP)
Protects the power supply during connection to the socket and from strong network fluctuations.
Under Voltage Protection (UVP)

Protects connected devices from low voltage current.
Color
Black

ATX Version

ATX 3.1
-

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

113,11 €
14,00 €   shipping cost
