The Epsolar EP-HY-5.0-G3 pure sine wave inverter is a hybrid model that connects directly to photovoltaic panels, as well as to a lithium or lead-acid battery. It stores surplus energy in the battery and can supply it to meet household needs, reducing reliance on the grid. Remote control and monitoring are available via the EPEVER app or web portal.
It allows the battery to be charged from the grid during off-peak hours and discharged during peak hours. It includes DC reverse-polarity protection and output overvoltage protection.
- Type: Pure sine wave
- Rated input voltage: 48 V
- Rated power: 5000 W
- Power supply: Single-phase
- Battery compatibility: Lithium or lead-acid
- Protection: DC reverse-polarity and output overvoltage protection
- Dimensions: 588 x 214 x 480 mm
- Weight: 32 kg
- Certifications: TÜV CE, TÜV IEC 62109-1&2, TÜV VDE 0126-1-1, TÜV, AS 4777&AS/NZS 3100, EN50549, SAA, G99, G100
- Type
- Pure Sine Wave
- Rated power
- 5000 W
- Nominal Input Voltage
- 48 V
- Power supply
- Single Phase
