Type: Multi-directional

Beam: Laser

Connectivity: RS-232

Reading Mode: 1D

Scanning Range/Depth of Field: 1.18 in - 5.91 in

Scanning Range/Field Width: 5 mil

Scanning Rate: 1333 line / sec

Resolution: 5 mil (0.127 mm)

Dimensions: 189 mm x 65 mm x 73 mm

Weight: 195 gr

Ambient Light: 4842 Lux

Sealing: Sealed for protection against airborne organisms.

Symbols: GS1 DataBar-14, GS1 DataBar Expanded, GS1 DataBar Limited

Additional Features:

• Voltage: 5 VDC ± 0.25 V
• Operating: 1.4 W (275 mA @ 5 V)
• Standby: 1.0 W (200 mA @ 5 V)
• Operating Temperature: -20°C to 40°C
• Storage Temperature: -40°C to 60°C
• Humidity: 5% to 95%
• Drop from 1.5 m
