Hensel Surface Mounted Electrical Box Branching Watertight IP66
Junction Boxes

Hensel Surface Mounted Electrical Box Branching Watertight IP66

Junction box 104 x 104 x 70 mm IP66/67 white KF 0400 H.

Features:

  • No clamps and walls without embossing.
  • Ability to open holes for filling boxes with a maximum size of M25.
  • Resistant to atmospheric...

Junction box 104 x 104 x 70 mm IP66/67 white KF 0400 H.

Features:

  • No clamps and walls without embossing.
  • Ability to open holes for filling boxes with a maximum size of M25.
  • Resistant to atmospheric effects (UV solar radiation, rain, temperature, mechanical effects).
  • Resistant to seawater for coastal applications.
  • Sealing capability of the cover without...
See Description & Specifications See Description & Specifications

Learn more about invoicing
Review the product
Product report

Description & Specifications

Junction box 104 x 104 x 70 mm IP66/67 white KF 0400 H.

Features:

  • No clamps and walls without embossing.
  • Ability to open holes for filling boxes with a maximum size of M25.
  • Resistant to atmospheric effects (UV solar radiation, rain, temperature, mechanical effects).
  • Resistant to seawater for coastal applications.
  • Sealing capability of the cover without additional components.
  • Includes external wall brackets and a strap that connects the cover to the base.
  • Color: grey, RAL 7035.

Technical specifications:

  • Wall thickness of the bottom: 2.0 mm.
  • Material: PC (polycarbonate) with GFS.
  • Protection degree: IP 66 / IP 67 / IP 69.
  • Submersion: up to 1 m for 15 minutes (IP 67).
  • Water pressure: max. 100 bar, water temperature: 80°C, distance => 0.15 m (IP 69).
  • Mounting width: 83 millimeters.
  • Installation height: 83 millimeters.
  • Maximum mounting depth: 55 mm.
  • Width: 104 millimeters.
  • Height: 104 millimeters.
  • Depth: 70 mm.
  • Weight: 0.137 kg.
  • According to IEC 60670-22 and DNV GL standards.

Manufacturer

Manufacturer Details

Warnings & Safety Information
Placement
Outdoor
Branching
Yes
Plasterboard
No
Protection Certification
IP66

Protection Certification

It is an indicator that shows us the degree of protection of the box. The indicator (I) which is the first number refers to protection from dust and the indicator (P) which is the second number refers to protection from water. The higher the numbers for each indicator, the better the protection.
Colour
White
Length
104 mm
Width
104 mm
Height
70 mm

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
