Radiator with a discreet, modern connection layout with an integrated thermostatic valve and child-friendly rounded edges.

The Novello radiators are made from special cold-rolled sheet metal quality EN 442-1, with side covers and a top grill cover. They are a complete heating element.

The sheet metal grooves appear every 33.3 mm. A transfer sheet is welded to the inner sides of the water channels.

The treatment of the outer surface consists of degreasing, iron phosphating, passivation, rinsing, and priming by cataphoretic dip coating according to DIN 55900 part 1 and baking.

The final surface treatment consists of high-quality electrostatic powder coating according to DIN 55900 part 2 and re-baking.

As standard, the radiators are equipped with an integrated valve assembly and a valve insert with integrated caps and an air vent.

Due to their design, type 11 radiators cannot be reversed. They are shrunk with a cardboard edge protector onto which the connectors are mounted.

The design meets the safety requirements of BAGUV.

• Connections: 6x 1/2"
• Connection: from the bottom or the right side
• Working overpressure: 10 bar
• Heat carrier temperature: hot water up to 110°C
• Type: 11
• Height: 600mm
• Length: 800mm
• Depth: 61 mm
• Output: 70/55/20°C: 636W
• Output: 55/45/20°C: 405W

{Material} Steel.

{Color} White.

{Connection} General connection (bottom and side).

{Output} up to 1000W.

{Width} 80 - 89 cm.

{Height} 60 - 69 cm.

{Connection type} Right.

{Type} Horizontal.
