The Satel AXD-200-DG wireless motion detector features PET immunity and antimasking protection. It supports selectable operating modes and can be configured as a dual-channel magnetic detector, a magnetic detector with a roller shutter input, a vibration and magnetic detector, a displacement detector, a temperature sensor, or a flood detector when used with the optional FPX-1 sensor.
It operates with the ABAX 2 and ABAX two-way wireless communication systems. Its open-area range is up to 2,000 m with the ACU-220 controller and up to 1,200 m with the ACU-280. Radio communication is two-way and encrypted.
- Power supply: Battery
- PET immunity: Yes
- Antimasking: Yes
- Operating modes: Dual-channel magnetic detector, magnetic detector with a roller shutter input, vibration and magnetic detector, displacement detector, temperature sensor, flood detector with the optional FPX-1 sensor
- Connection: Wireless
- Mounting: Wall-mounted
- Ingress protection rating: IP54
- Compatibility: ABAX 2 (ACU-220, ACU-280, ARU-200), ABAX (ACU-120, ACU-270, ARU-100, INTEGRA 128-WRL)
- Open-area range: Up to 2,000 m with ACU-220, up to 1,200 m with ACU-280
- Communication: Two-way encrypted radio communication
Specifications
- Protection Certification
- IP54
- Connector
- Wireless
- Battery
- Yes
Additional Features
- Antimasking
- Yes
- Tamper
- No
- Curtain
- No
- Placement
- Wall
- Recessed
- No
- PET
- Yes
- Built-in Camera
- No
