Orno Adjustable Day / Night Photocell 2-100 Lux IP65
Day / Night Photocells

Orno Adjustable Day / Night Photocell 2-100 Lux IP65

The ORNO OR-CR-231 love sensor is designed for automatic control of lighting or other electrical devices, contributing to energy savings. It starts or stops the electrical circuit when the light...

The ORNO OR-CR-231 love sensor is designed for automatic control of lighting or other electrical devices, contributing to energy savings. It starts or stops the electrical circuit when the light intensity falls below a certain level.

It features an external sensor in a sealed housing, which can be connected with a cable up to 15 meters long. It is suitable...

See full description See full description

  • Brightness Lux

    Specifies the brightness level (in lux) at which the photocell activates or deactivates the lights.

    At low lux values (e.g. 5-20 lux), it means that the photocell will turn on the lights very late, when it is almost completely dark.

    At high lux values (e.g. 50-100 lux), it means that the photocell will turn on the lights very early, already at dusk or when the weather is simply cloudy.

  • Adjustable

    With a switch that allows the lux value to be set to the desired level.

  • Protection Certification

    IP65

    Suitable for outdoor areas with heavy rain or pressurized water. Provides complete protection against dust and object intrusion, ideal for gardens or industrial areas.

  • Maximum Load

    Indicates the maximum total power (in Watts) of the lamps/lighting fixtures that can be safely connected to the photocell.

  • Operating Voltage

    It is the network voltage (in Volts) to which the photocell must be connected in order to operate properly.
  • See all
Review the product
Product report

Description

Description

The ORNO OR-CR-231 love sensor is designed for automatic control of lighting or other electrical devices, contributing to energy savings. It starts or stops the electrical circuit when the light intensity falls below a certain level.

It features an external sensor in a sealed housing, which can be connected with a cable up to 15 meters long. It is suitable for both indoor and outdoor use. It is designed for mounting on a DIN rail.

  • Maximum load: 3000W
  • Degree of protection (IP): 20 / 65
  • Sensor dimensions - width: 35 mm
  • Adjustable natural light sensor (LUX): yes
  • Sensor dimensions - height: 66 mm
  • Installation: DIN rail
  • Adjustable range of natural light sensor (LUX): <2-100lux
  • Sensor dimensions - depth: 90 mm
  • Type of sensor: Dawn
  • Maximum LED source load: 750W
  • Color: White
  • Usage: Indoor / Outdoor
  • Material: PVC
  • Package contents: 1 x Dawn Sensor
  • Power type: 230 V
  • Used for: Lighting control
  • Wiring: Wired
  • Number of sensors: 1

Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Protection Certification
IP65

Protection Certification

IP65

Suitable for outdoor areas with heavy rain or pressurized water. Provides complete protection against dust and object intrusion, ideal for gardens or industrial areas.
Operating Voltage
230V

Operating Voltage

It is the network voltage (in Volts) to which the photocell must be connected in order to operate properly.
Brightness Lux
2-100 Lux

Brightness Lux

Specifies the brightness level (in lux) at which the photocell activates or deactivates the lights.

At low lux values (e.g. 5-20 lux), it means that the photocell will turn on the lights very late, when it is almost completely dark.

At high lux values (e.g. 50-100 lux), it means that the photocell will turn on the lights very early, already at dusk or when the weather is simply cloudy.
Maximum Load
3000 W

Maximum Load

Indicates the maximum total power (in Watts) of the lamps/lighting fixtures that can be safely connected to the photocell.
Adjustable
Yes

Adjustable

With a switch that allows the lux value to be set to the desired level.

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications

Description & Specifications

The ORNO OR-CR-231 love sensor is designed for automatic control of lighting or other electrical devices, contributing to energy savings. It starts or stops the electrical circuit when the light intensity falls below a certain level.

It features an external sensor in a sealed housing, which can be connected with a cable up to 15 meters long. It is suitable for both indoor and outdoor use. It is designed for mounting on a DIN rail.

  • Maximum load: 3000W
  • Degree of protection (IP): 20 / 65
  • Sensor dimensions - width: 35 mm
  • Adjustable natural light sensor (LUX): yes
  • Sensor dimensions - height: 66 mm
  • Installation: DIN rail
  • Adjustable range of natural light sensor (LUX): <2-100lux
  • Sensor dimensions - depth: 90 mm
  • Type of sensor: Dawn
  • Maximum LED source load: 750W
  • Color: White
  • Usage: Indoor / Outdoor
  • Material: PVC
  • Package contents: 1 x Dawn Sensor
  • Power type: 230 V
  • Used for: Lighting control
  • Wiring: Wired
  • Number of sensors: 1

Manufacturer

Manufacturer Details

Warnings & Safety Information
Protection Certification
IP65

Protection Certification

IP65

Suitable for outdoor areas with heavy rain or pressurized water. Provides complete protection against dust and object intrusion, ideal for gardens or industrial areas.
Operating Voltage
230V

Operating Voltage

It is the network voltage (in Volts) to which the photocell must be connected in order to operate properly.
Brightness Lux
2-100 Lux

Brightness Lux

Specifies the brightness level (in lux) at which the photocell activates or deactivates the lights.

At low lux values (e.g. 5-20 lux), it means that the photocell will turn on the lights very late, when it is almost completely dark.

At high lux values (e.g. 50-100 lux), it means that the photocell will turn on the lights very early, already at dusk or when the weather is simply cloudy.
Maximum Load
3000 W

Maximum Load

Indicates the maximum total power (in Watts) of the lamps/lighting fixtures that can be safely connected to the photocell.
Adjustable
Yes

Adjustable

With a switch that allows the lux value to be set to the desired level.

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
